IBM x3650 M3 Product Guide

IBM System x3650 M3 17
Controllers for internal storage
The following table lists the RAID controllers and additional options used for internal disk storage of x3650
M3 server.
Table 8. RAID controllers for internal storage
Part
number
Feature
code
Description Maximum
supported
Standard models
where used
46M0969* 3889 ServeRAID B5015 SSD Controller 1 -
49Y4731 9742 ServeRAID BR10il SAS/SATA Controller v2 1 A2x, 12x
81Y4492 A1XL ServeRAID H1110 SAS/SATA Controller for IBM System x 1 -
46M0831 0095 ServeRAID M1015 SAS/SATA Controller 1 B2x, C2x, D2x, H2x,
N2x, 22x, 32x, D4x
46M0916 3877 ServeRAID M5014 SAS/SATA Controller 1 F2x, G2x, 52x, 54x,
62x
46M0829 0093 ServeRAID M5015 SAS/SATA Controller 1 or 2** J2x, L2x, M2x, JSx,
H4x, J4x, J6x, JCx,
L4x, 72x, 82x
90Y4304 A2NF ServeRAID M5016 SAS/SATA Controller for IBM System x 1 -
46M0830 0094 ServeRAID M5025 SAS/SATA Controller 1 -
43W4296* 3571 ServeRAID MR10i SAS/SATA Controller 1 -
46M0832 9749 ServeRAID M1000 Series Advance Feature Key 1 -
46M0930 5106 ServeRAID M5000 Series Advance Feature Key 1† -
46M0917 5744 ServeRAID M5000 Series Battery Kit 1 J2x, L2x, M2x, JSx,
H4x, J4x, J6x, JCx,
L4x, 72x, 82x
68Y7396 5862 ServeRAID M5000 Series Battery Remote Mount Cable 1 -
81Y4426 A10C ServeRAID M5000 Series Performance Accelerator Key 1† -
* Withdrawn from marketing
** When this RAID controller is ordered separately, then the maximum quantity supported is one. When this RAID
controller is ordered as a part of the 69Y5034 upgrade (see Table 6), then the maximum quantity supported is two.
† Only one key is supported in each controller, either the Advance Feature Key or the Performance Accelerator Key.
When the maximum number of HDD bays is eight, the RAID controller occupies a dedicated PCIe slot on
x3650 M3 and does not consume the regular PCIe slot. When 16 HDD bay configurations are used, the
number of available regular PCIe slots is three.
The ServeRAID BR10il v2 SAS/SATA Controller has the following specifications:
One Mini-SAS internal connector

Supports RAID levels 0, 1, and 1E

3 Gbps throughput per port

Based on the LSI 1064E controller

PCI Express 2.0 x4 host interface

Stripe size: 64 KB (fixed)

