IBM x3650 M3 Product Guide

IBM System x3650 M3 33
External disk storage expansion
The external disk storage expansion enclosures listed in the following table are available.
Table 20. External storage expansion enclosures
Part number Description Maximum quantity
supported per one M5025
172701X IBM System Storage® EXP3000 18 (9 per port)
174712X IBM System Storage EXP2512 Express 18 (9 per port)
174724X IBM System Storage EXP2524 Express 9 (9 per port)
The hard disk drives listed in the following table are supported with external expansion enclosures.
Table 21. Hard drive options for external expansion enclosures (Part 1)
Part number Description Maximum quantity supported
per one enclosure
EXP3000 Hot-Swap SATA 3.5" Hard Drives
43W7630 1000 GB Dual Port Hot Swap SATA 12
49Y1940 IBM 2 TB 7200 Dual Port SATA 3.5'' HS HDD 12
EXP3000 Hot-Swap SAS 3.5" Hard Drives
44W2234 IBM 300 GB 15K 6 Gbps SAS 3.5" Hot-Swap HDD 12
44W2239 IBM 450 GB 15K 6 Gbps SAS 3.5" Hot-Swap HDD 12
44W2244 IBM 600 GB 15K 6 Gbps SAS 3.5" Hot-Swap HDD 12
EXP2512 Hot-Swap SAS 3.5" Hard Drives
49Y1899 300 GB 15K 6 Gb SAS 3.5" HDD 12
49Y1900 450 GB 15K 6 Gb SAS 3.5" HDD 12
49Y1901 600 GB 15K 6 Gb SAS 3.5" HDD 12
49Y1903 1 TB 7,200 RPM 6 Gb SAS NL 3.5" HDD 12
43W7630 1000 GB Dual Port Hot Swap SATA 12
49Y1902 2 TB 7,200 RPM 6 Gb SAS NL 3.5" HDD 12
90Y8720 3 TB 7,200 RPM 6 Gb SAS NL 3.5" HDD 12

IBM x3650 M3 Specifications

General

Memory	Up to 192 GB DDR3
Memory Slots	18 DIMM slots
Form Factor	2U Rack
Processor	Intel Xeon 5600 series
Storage	SAS/SATA drives
Network Interface	Gigabit Ethernet ports
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
RAID Support	IBM ServeRAID options available
