IBM System x3650 M3 35
The external SAS cables listed in the following table are supported with external expansion enclosures
and M5025 RAID controllers.
Table 23. External SAS cables for external storage expansion enclosures
Part number Description Maximum quantity
supported per enclosure*
39R6531 IBM 3 m SAS Cable 1
39R6529 IBM 1 m SAS Cable 1
* Note: The EXP3000 and EX2500 series can be chained with each other. In such a case, one cable is used to
connect first EXP25xx or EXP3000 to the RAID controller, and every consecutive EXP unit is connected to previous
one by one cable.
External disk storage systems
The following table lists the external storage systems that are supported by the server and can be ordered
through System x sales channel. The server may support other IBM disk systems that are not listed in this
table. Refer to IBM System Storage Interoperability Center for further information,
http://www.ibm.com/systems/support/storage/ssic.
Table 24. External disk storage systems
Part number Description
1746A2D IBM System Storage DS3512 Express Dual Controller Storage System
1746A2S IBM System Storage DS3512 Express Single Controller Storage System
1746A4D IBM System Storage DS3524 Express Dual Controller Storage System
1746A4S IBM System Storage DS3524 Express Single Controller Storage System
181494H IBM System Storage DS3950 Model 94
181498H IBM System Storage DS3950 Model 98
181492H IBM System Storage EXP395 Expansion Unit
1746A2E IBM System Storage EXP3512 Express Storage™ Expansion Unit
1746A4E IBM System Storage EXP3524 Express Storage Expansion Unit
For more information, see the list of IBM Redbooks Product Guides in the Storage Systems category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=externalstorage
