16. Ext Amplifier & EXT Amplifier in.
An external amplifier can be connected to EXT. Amplifier XLR out (51) and EXT. AMP In (52)
The external amplifier can act as a spare amplifier or call amplifier.
It is decided by the mode settling dip switch (24).
Please refer to the mode dip switch setting.
17. REC out/Power in/PRE out.
The REC. Out RCA connector can be connect to tape recorder or other recording equipment
to record signal. Use shorting bar to short between power in and PRE out or use RCA cable
to connect with external audio processor.
MT-AMP 1000
ic audio GmbH
Boehringerstraße 14a; D-68307 Mannheim; Germany
Fon: + 49(0) 621 / 77096-0; Fax: + 49(0) 621 / 77096-26
E-Mail: info@ic-audio.com; www.ic-audio.com
EN
20
