25. Technical specifiactions
Power Source 115/230V AC , 50/60 Hz, 24V dc
Rated Output 240W
Amp Type Analog
Power Consumption 720W
MIC: 60 - 15KHz +1/-3dB Frequency Response
AUX: 50 - 20KHz +1/-3dB
Distortion
1% rated output power
MIC 1 - 6: 1.5mV,600Ω,balanced
XLR terminal/RJ45 terminal(MIC 1)
LINE 1 - 2: 200mV,600Ω,balanced
XLR terminal
MIC 5/LINE 1, MIC6 /LINE 2 switchable
AUX 1: 500mV, 10KΩ,unbalanced
XLR terminal
AUX 2: 500mV,10KΩ,unbalanced
RCA terminal
AUX 3: 300mV,10KΩ,unbalanced
RCA terminal
Power In:
1V, 600Ω, unbalanced
RCA terminal
Paging Station: 1V, RJ45 terminal
TEL/EMEG: 100mV, 600Ω, balanced
Input
Wall Control Panel: 1V, RJ45 terminal
100V Input 100V, balanced Input
Ext Amp in: 100V input
REC Out: 1V, unbalanced, RCA Jack.
PRE Out: 1V, unbalanced, RCA Jack.
Ext. Amplifier XLR out: 1V, balanced, XLR Jack.
MOH 0/8Ω: 8Ω,1W, unbalanced
MOH 600Ω: 600Ω, output,1Vrms, balanced
Direct Output: 100V - 70V - 8Ω - 0.
To PEX-8000: RJ45 terminal
Output
Z1 - Z6 Output: 100V - 0
Phantom Power ON / OFF,MIC 1 - 6, 16V dc.
MIC 1 - 4: > 60 dB
TEL: > 70 dB
MIC 5 - 6: > 60 dB
LINE 1 - 2: > 70 dB
S/N Ratio
AUX 1 - 3: > 75 dB
Tone Control Bass: ±10dB, 100Hz, Treble: ±10dB, 10KHz
Wall control panel: RJ45 socket , operate under PX-8240
selector setting at “REMOTE”
Remote Power: Dry contact terminal
Open Voltage: 24V DC
Control Input
(when the unit's power is at "OFF" position)
Short circuit to switch ON the unit.
