27
MT-AMP 1000
ic audio
Output level meter: 4 LED
Power indicator: 1 LED (Blue)
Zone LED: Each Zone one LED (Green )
Remote/Source/AUX1~3: 5 LED (Green)
Indicator
Fault LED: 1 LED (Amber)
Control Output: To MT-EXP 1000: RJ45 terminal
MODE 1/2: 1 DIP switch to select MODE 1 or MODE 2
20KHz: 1 DIP switch to select ON/OFF
MIC Pri:
2 DIP switches to select 4 different priority
modes
DIP Switch Setting
Chime: 2 DIP switches to set 4 different chime modes
MIC 1~6: Rotary
Source/AUX 1~3: Rotary
Vol. Control:
Master: Rotary
VOX Mute Level: Rotary
TEL Level: Rotary
MOH Level: Rotary
Level Control:
Chime Level: Rotary
Zone Output Att. Zone 1~6: Rotary, 6 steps
ZONE 1~6: 6 tact switches
ALL: 1 tact switch
Remote/Source/AUX1~3: 1 tact switch
Switches:
Power Switch: Rocker type
Operating Temperature:
-10 45
Dimension (H×W×D): 133×430×365 mm
Weight: Approx 18.0kg
Mounting options Table Top or 19" Rack Mountable
* 0dB = 1V
* -20dB = 0.1V
* -60dB = 1mV
* Load: MT-AMP 1000: 42Ω
