PEACH
10
Note: For Australian market the shape
of the bumper bar will differ slightly.
Operation and fitting is not affected.
9. Bumper bar: Attach the Bumper Bar
with the inclined angle towards the foot
end of seat unit. Ensure both locking-
tabs fully engage. Check security by
pulling bar upwards.
10. Removal of bumper bar: Depress
both locking tabs firmly inwards and lift
from sockets.
11. Attaching seat unit: Insert the seat
unit into the main connectors on the
chassis. Push down on each side of the
seat frame to engage.
12. Check that both locking tabs are
flush with the chassis hub slots before
use. The Seat Unit can be positioned to
face you or face forwards.
devic
WARNING: Check that the seat unit
attachment devices are correctly
engaged before use.
9
10
11
12
