MICROmatic MINImatic MIDImatic - MULTImatic
Sistemi di rifasamento automatici
Manuale operativo di installazione, uso e manutenzione
Automatic power factor correction systems
Installation, operating and maintenance instruction manual
Systèmes de compensation de l’énergie réactive
Manuel opératif d’installation, utilisation et entretien
MAT 189 revJ Jan2018

Questions and Answers

  • M
    Margaret CampbellAug 9, 2025
    Why won't the capacitor banks switch in on my Icar MULTImatic Portable Generator?
    • W
      Walter PriceAug 9, 2025
      If the Icar Portable Generator's controller doesn't switch in the capacitor banks, ensure the current transformer is correctly positioned upstream of all loads and power factor correction. Also, verify that the current transformer is enabled on phase L1 (R) and that the controller is not set to manual mode. If the amperage of the current transformer is lower than the sensitivity threshold, increase the load current or use a current transformer with an adequate primary ratio.
  • E
    ezimmermanAug 15, 2025
    Why does my Icar MULTImatic Portable Generator controller show an unreal power factor?
    • C
      christopherlittleAug 15, 2025
      If your Icar Portable Generator controller displays an unreal power factor, the current transformer may be enabled on the incorrect phase. Ensure it is positioned on phase L1 (R) as referred to in our cabinet. If the issue persists, the current transformer itself may be faulty and require replacement with a suitable one.
  • C
    cassandraeatonAug 21, 2025
    What to do if my Icar MULTImatic Portable Generator switches in all capacitor banks but the power factor doesn't increase?
    • S
      Suzanne HunterAug 21, 2025
      If the Icar Portable Generator controller switches in all the capacitor banks without increasing the power factor on the display, it might be due to the current transformer being installed at an incorrect point. Ensure it's positioned upstream of all the loads and power factor correction system. Also, check that the current transformer is enabled on phase L1 (R) as referred to in our cabinet.
  • M
    Maria WalkerAug 27, 2025
    How to fix an Icar Portable Generator controller that won't switch on?
    • R
      rebecca95Aug 27, 2025
      If the Icar Portable Generator controller fails to switch on, first ensure the disconnect switch is turned on. If it still doesn't power up, check for blown control circuit fuses and replace them after identifying the cause. Also, verify that the quick connect terminal boards inside the unit are correctly engaged. If these steps don't resolve the issue, check the controller's power supplies; if they are regular, replace the controller with one of the original type.
  • T
    Tamara HoltSep 2, 2025
    What to do if Icar Portable Generator controller switches capacitor banks in and out without balance?
    • Z
      Zachary WebsterSep 2, 2025
      If the Icar Portable Generator controller switches the capacitor banks in and out continually without finding a balance, it is likely due to a faulty setting of the controller parameters. Check the current parameters and set them correctly.

Summary

ENGLISH

Preliminary Operations

Safety precautions for personnel and product before working on the system.

2 ENVIRONMENTAL CONDITIONS

4 CONNECTION TO MAIN POWER SUPPLY

Phase Connection

Connecting three phases to terminals L1, L2, L3 via power cables.

Current Transformer Connection

Connecting secondary of CT to terminals S1/S2 (S11/S12) on phase L1.

Pre-Operation Checks

Checking mains voltage, closing openings, refitting guards before powering up.

5 REACTIVE POWER CONTROLLER

6 START-UP AND OPERATION

Pre-Powering Connection Checks

Checking connections and tightening before powering up the unit.

Initializing the Unit

Presetting primary value on CT and checking manual mode operation.

7 TROUBLE SHOOTING DURING INSTALLATION

Controller Fails to Switch On

Troubleshooting steps for unresponsive controller (LEDs/display off).

Controller Fails to Switch Capacitor Banks

Troubleshooting steps for controller not switching capacitor banks.

Controller Displays Unreal Power Factor

Troubleshooting steps for incorrect power factor readings.

Incorrect Capacitor Bank Switching

Troubleshooting steps for incorrect capacitor bank switching.

Continuous Capacitor Bank Switching

Troubleshooting steps for continuous switching without balance.

8 MAINTENANCE

8.1 Routine Maintenance Checks

Periodic checks for current, electronics, fuses, filters, contactors, and capacitors.

Replacement of Capacitors

Replacing capacitors due to faults like overpressure device trip or low current.

8.4 Safety Recommendations

Critical safety advice, including not operating under load or modifying units.

9 INFORMATION AND TECHNICAL SERVICE

11 ALLEGATO; ANNEX; ANNEXE B

14 ALLEGATO; ANNEX; ANNEXE E

Icar MULTImatic Specifications

General IconGeneral
Engine Type4-Stroke OHV
Starting SystemRecoil Start
Fuel TypePetrol
Fuel Tank Capacity4.8L
Outlet Types1x 12V DC
