DATE
7/9/01
DESCRIPTION
#CS2052X - MAIN/WAGON LOWER HARNESS
DRAWN BY
MMARTIN
FILENAME
CS.VSD
PAGE
6 OF 16
REVISED
2/6/02
TITLE
SNACK ATTACKER
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15
15 PIN PLUG #2144 SPLIT PIN #2100
Crane Fwd Sw
Crane Back Sw
Claw Dwn Sw
Claw Up Sw
Gnd
Front/Back Motor +
Front/Back Motor -
Left/Right Motor +
Left/Right Motor -
Up/Down Motor +
Up/Down Motor -
Solenoid -
Solenoid +
Gnd
2 PIN CAP #2181 FEMALE PIN #2102
1 2
Home Sw
Gnd
1 2 3 4 5
5 PIN AMP HOUSING #2419 CONTACT PIN #2201
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15
15 PIN PLUG #2144 SPLIT PIN #2100
MotUp MotDn HomeL/R ClawUp ClawDn Claw - Gnd Gnd MotRight MotBack HomeF/B MotLeft MotFwd Claw + 36V
Crane Fwd Sw
red white green brown black YELLOW BLUE ORANGE GREEN BROWN RED * BROWN * BLUE blue
BROWN
RED
pink
brown
green
* BROWN
black
black + blue
ORANGE
YELLOW
white
GREEN
BLUE
* BLUE
pink black
#2997 - 2 CONDUCTOR POWER CORD
93 "
P1
95 "
red
25 "
To Main Board
To Wagon/Crane
Harness
PX4
To Sensor
Asssembly
To Main Board
