ICE Games SNACK ATTACK - Page 30

30
D C
B A
4321
D C
B A
4321
DATE
7/9/01
DESCRIPTION
#CS2053X - WAGON HARNESS (Part of CS1055X WAGON)
DRAWN BY
MMARTIN
FILENAME
CS.VSD
PAGE
7 OF 16
REVISED
2/6/02
TITLE
SNACK ATTACKER
15 PIN CAP #2367 FEMALE PIN #2102
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15
CRANE FWD SW
CRANE BACK SW
CLAW DOWN SW
CLAW UP SW
COMMON
FRONT/BACK MOTOR +
FRONT/BACK MOTOR -
LEFT/RIGHT MOTOR +
LEFT/RIGHT MOTOR -
UP/DOWN MOTOR +
UP/DOWN MOTOR -
SOLENOID - (PIN 1)
SOLENOID + (PIN 2)
COMMON
EARTH GROUND
violet black (existing) black (flex) red (flex) orange (flex) blue blue/white green green/white yellow (flex) green (flex) violet (flex) white (flex) black (existing) + black/white green/yellow * 2
1
2
4
3
CRANE
FWD SW
CRANE
BACK SW
FRONT/BACK MOTOR
LEFT/RIGHT MOTOR
UP/DOWN MOTOR
#PC20217 #PC20217
#2513 #2513
black black
violet
black/white
black black
green/yellow green/yellow
violet (flex)
white (flex)
yellow (flex)
green (flex)
blue
blue/white
green
green/white
black (flex)
orange (flex)
red (flex)
orange
4-1/2 "
34-1/2 "
34 "
34-1/2 "
34-1/2 "
7 "
36 "
10-1/2 "
35-1/2 "
37-1/2 "
To 15 - pin
Bracket
To Crane Wagon
37 "
#2959 - CAP. (274-002) VANCO CBC4PX
#CS2008
#CS2008
#CS2008
#CS2008 - MOTOR GLOBE 415A-541
#CS2008 - MOTOR GLOBE 415A-541 #CS2008 - MOTOR GLOBE 415A-541
#8452 - SWITCH (SPDT) V3L-1123-D8 MICR
#8422 - MICROSWITCH UM50E10F01
#CG2012 - SENSOR (HAMLIN 59145-010)
#CG2012 - SENSOR (HAMLIN 59145-010)
#8005
#8005
#8005
