ICE Games SNACK ATTACK - Page 31

31
D C
B A
4321
D C
B A
4321
DATE
7/9/01
DESCRIPTION
#CS2054X - DISPLAY HARNESS
DRAWN BY
MMARTIN
FILENAME
CS.VSD
PAGE
8 OF 16
REVISED
2/6/02
TITLE
SNACK ATTACKER
1 2 3 4 5 6 7 8 9
10 11 12
12 PIN PLUG #2106 SPLIT PIN #2100
1 2 3 4 5 6 7 8 9
10 11 12
12 PIN PLUG #2106 SPLIT PIN #2100
brown red/black orange/black yellow green blue ORANGE gray white black/white tan BLACK
Seg a Seg b
Seg c
Seg d Seg e
Seg f
+12v
Seg h Seg g
Sel 1 Sel 2
ground
P6
DISPLAY
TO MAIN PCB
TO DISPLAY
PCB
P1
62 "
brown
red/black
orange/black
yellow
green
blue
ORANGE
gray
white
black/white
tan
BLACK
