ICE Games SNACK ATTACK - Page 32

32
D C
B A
4321
D C
B A
4321
DATE
7/9/01
DESCRIPTION
#CS2055X - POWER BOX HARNESS
DRAWN BY
MMARTIN
FILENAME
CS.VSD
PAGE
9 OF 16
REVISED
2/6/02
TITLE
SNACK ATTACKER
A B C D
#651
.187
#651
.187
#638
.187
3 PIN CAP #2288 FEMALE #2102
1 2 3
#PC20217
#PC20217
GREEN/YELLOW
BROWN BLUE
GREEN/YELLOW
BROWN
BLUE
12 " 12 "
20 "
4 "
To Bracket
To Transformer
PELSOSSXO
#HH2048F - FUSE MDQ-4 4AMP SLO-BLO #2892 - POWER MODULE CORCOM PELS0SSX0
#CC3007 - WORKBOX (SINGLE) #RC1001 - BRACKET (POWER MODULE)
