ICE Games SNACK ATTACK - Page 41

41
230v Version 2-51-97102
1 2 3
3 PIN PLUG #2206 20-14 AWG PIN MALE#8260
1 2
2 PIN CAP #2181 FEMALE PIN #2102
1 2
WHITE BROWN
BLACK BLACK
BLACK BLACK
To DBV
120v To
Brightstick
230v 50hz
10.5v ac @ 3.0 A ac 90%
16.5v ac @ 3.5 A ac 85%
36v ac @ 3.5 A ac 60%
13.2v ac @ 2.0 A ac 100%
BLUE BLUE
ORANGE ORANGE YELLOW YELLOW RED RED
KEY
"
36
PR1 230vac
120v @ .8a 100%
"
13
"
8
"
12
DATE
7/12/00
DESCRIPTION
220 Transformer
DRAWN BY
CHERYLZ1 RMO
FILENAM E
LC220STEPDOWN
.VSD
PAGE
1 OF 1
REVISED
8/2/00
TITLE
1 3 5 2 8 4 7 6 9
9 PIN PLUG #2292 20-14 AWG MALE #8260
#2835-BRAID
25" OVERALL
GREEN/YELLOW
"
25
**APPLY 3" OF1/2"
SHRINK TUBE TO
BOTH ENDS OF THE
BRAID.
***OVER THE BRAID PUT
#2955-BLACK SPIRAL
WRAP 25" LONG .
#652
#LC2002CEX
***ADD #8070-FERRITE
TO GROUND WIRE
2 PIN CAP #2181 FEMALE PIN #8269
