ICE Games SNACK ATTACK - Page 40

40
D C
B A
4321
D C
B A
4321
DATE
7/2/98
DESCRIPTION
110v TRANSFORMER
20" GROUND
DRAWN BY
RMO RMO
FILENAM E
LC.VSD
PAGE
4 OF 4
REVISED
8/31/00
TITLE
#LC2002X / #LC2004X
TO DBV EXT.
110v ICE# CG2002
2-51-9813
1 3 5 2 8 4 7 6 9
9 PIN PLUG #2292 20-14 AWG #8260
10.5v ac @ 3.0 A ac 90%
16.5v ac @ 3.5 A ac 85%
36v ac @ 3.5 A ac 60%
13.2v ac @ 2.0 A ac 100%
BLUE BLUE ORANGE ORANGE YELLOW YELLOW RED RED
KEY
"
36
BLACK WHITE
TO WORK
BOX
PRIMARY 120v ac
"
13
"
6
1 2 3
BLACK WHITE
"
12
TO LAMPS
SECONDARY
PER GAME1QTY
TRANSFORMER
1 2
BLACK WHITE
#652-RING #PC20217-RING
2 PIN CAP #2181 FEMALE PIN #2102
1 2
#LC2004X-20"GROUND
B
A
3 PIN PLUG #2206 MALE PIN #2422
2 PIN CAP #2181 FEMALE PIN #2013
