ICE Games SNACK ATTACK - Page 39

39
D C
B A
4321
D C
B A
4321
DATE
7/9/01
DESCRIPTION
#CS8449X - BALLAST ASSEMBLY
DRAWN BY
MMARTIN
FILENAME
CS.VSD
PAGE
16 OF 16
REVISED
2/6/02
TITLE
SNACK ATTACKER
#8449 - Workhorse 3 Ballast
1 2 3
3 PIN PLUG #2206 PIN 2 :SOLID PIN #2100S PINS 1 & 3: 20-14 AWG PIN #8260
#653T
.250
#653T
.250
RED
YELLOW
#PC20217
BLACK GREEN/YELLOW WHITE
10 " 10 "
6 "
5 "
10 "
RED
* Place splice on end of wire Fold back and zip tie to other red wire
#8492
