ICE Games SNACK ATTACK - Page 38

38
D C
B A
4321
D C
B A
4321
DATE
7/9/01
DESCRIPTION
#CS2090X - ROPELIGHT SPLITTER HARNESS (PART OF DOME OPTION)
DRAWN BY
MMARTIN
FILENAME
CS.VSD
PAGE
15 OF 16
REVISED
2/6/02
TITLE
SNACK ATTACKER
1 2 3 4 5
5 PIN AMP HOUSING #2419 CONTACT PIN #2201 BROWN BLACK BLUE
#2558 #2558 #2558
BROWN
BLACK
BLUE
GREEN BLACK WHITE
#2874 - SJO
#2558
GREEN BLACK WHITE
BROWN
BLACK
BLUE
4-3/4 "
2 " STRIP
2 "
6-3/4 "
1 " STRIP
1 " STRIP
1 " STRIP1 " STRIP
52 "
Cut 2" from base of Y splitter Add SJO cord with splices(red) at end of SJO cord Splice remaining piece of connector with splices(red) P2
#2133S - SPLITTER
