ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
SOLUTION TANK GROUP
DIA
NO.
PART
NUMBER
SERIAL NUMBER
DESCRIPTION
NO
REQ'D
1 8113115 000101- DOWN PRESSURE LABEL 1
2 8113101 000101- DOWN PRESSURE LEVER BRACKET 1
3 1421816 000101- FLAT WASHER M8×
∮
16×1.6 2
4 1422821 000101- LOCK WASHER M8 2
5 1021820 000101- HEX BOLT M8×20 2
6 8113104 000101- BALL KNOB 1
7 8113106 000101- DOWN PRESSURE LEVER 1
8 8113112 000101- BUSHING 1
9 8113110 000101- SLEEVE, P/M 1
10 8113111 000101- NYLON FLAT WASHER
∮
12.9×
∮
25.4×0.8 2
11 8113109 000101- THRUST BEARING 2
12 8113114 000101- SPRING 1
13 8113107 000101- RETAINER, SPRING 1
14 8113103 000101- BOLT M6×18 1
15
8113108 000101- LINK, SPRING 2
8133108 000101- LINK, SPRING, ORBITAL HEAD MODEL 2
16 1123608 000101- LOCK NUT M6 1
17 1221512 000101- SCREW M5×12 15
18 1123507 000101- LOCK NUT M5 1
19 8133113 000101- SPRING 1
20 8133501 000101- CARGO NET 1
21 8133502 000101- CLAMP 4
22 1221412 000101- SCREW M4X12 4
23 8133008
000528- for i20NB
CLEAN TUBING 1
000604- for i20NBT
000322- for i24BT
000165-00527 for i20NB
000187-000603 for i20NBT
000139-000321 for i24BT
24 1962025 000101- CLAMP 16-25mm 1
25 8133001 000101- SOLUTION TANK 1
26 8119005 000101- BALL VALVE, G1/2 1
27 8119007 000101- ELBOW G1/2 1
28 8113021 000101- HANDLE, CONNECTOR 1
29 8113020 000101- CONNECTOR 2
