ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
SOLUTION TANK GROUP
DIA
NO.
PART
NUMBER
SERIAL NUMBER
DESCRIPTION
NO
REQ'D
30 8114731 000101- BATTERY CONNECT CABLE, ASSEMBLY 1
31 8113013 000101- SPACER, BATTERY 2
32
8113011 000101- BATTERY, 12TB115, 115AH, HOPPECKE 2
8133010 000101- BATTERY, 6-EVF-100, 110AH, CHILWEE 2
8133020 000101- BATTERY, EV12A-A, 120AH, DISCOVER 2
34 8114750 000101- BATTERY CONNECT CABLE, BLACK 1
35 8114751 000101- JACKET, BATTERY TERMINAL, BLACK 4
36 1421510 000101- FLAT WASHER M5×
∮
10×1 17
37 8119100 000101- FILTER ASSEMBLY 1
38 8133025 000101- LABEL, LEFT SIDE 1
39 1321110 000101- SELF-TAPPING SCREW ST3.5 ×10 4
40 1421409 000101- FLAT WASHER M4×
∮
9×0.8 5
41 8133610 000101- LED LIGHT, KIT 1
42 8133601 000101- LED LIGHT MNTG BASE 1
43 1221520 000101- SCREW M5X20 3
44 8133602 000101- LED LIGHT COVER 1
45 8113030 000101- SEAL 1
46 8113002 000101- COVER 1
47 8113007 000101- STRAP 1
48 1321213 000101- SELF-TAPPING SCREW ST4.2X13 1
49 4010316 000101- ICE Logo 2
50 8133026 000101- LABEL, RIGHT SIDE 1
51 1123305 000101- LOCK NUT M3 2
52 8113010 000101- BRACKET, CONNECTOR MTG 1
53 1434300 000101- LOCK WASHER, TOOTH, M3 2
54 1211325 000101- SCREW M3×25 2
55 8134783 000101- BATTERY CONNECT CABLE, ASSEMBLY 1
56 1422513 000101- LOCK WASHER M5 2
57 8133002 000101- CAP, SOLUTION FILL 1
58 8113009 000101- NYLON, CLAMP 9
