Ice i20NBT User Manual

72
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
SOLUTION GROUP
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
1 8119007 000101- ELBOW G1/2 1
2 8119005 000101- BALL VALVE, G1/2 1
3 8119006 000101- CLAMP 5
4 8119201 000101- TUBING ID=12MM L=70MM 1
5 8119002 000101- ELBOW, TUBING BARB 2
6 8119202 000101- TUBING ID=12MM L=100MM 1
7
8119100 000101- FILTER ASSEMBLY, 70 MESH 1
8119200 000101- FILTER ASSEMBLY, 40 MESH 1
8 8119101 000101- BASE, FILTER ASSEMBLY 1
9
8119103 000101- SCREEN, FILTER, 70 MESH 1
8119105 000101- SCREEN, FILTER, 40 MESH (OPTION) 1
10 1622760 000101- O RING 1
11 8119102 000101- CAP, FILTER ASSEMBLY 1
12 1421510 000101- FLAT WASHER M5×
∮
10×1 2
13 1221512 000101- SCREW M5×12 2
14 8119202 000101- TUBING ID=12MM L=100MM 1
15 1221412 000101- SCREW M4×12 2
16 1422411 000101- LOCK WASHER M4 2
17 1421409 000101- FLAT WASHER M4×
∮
9×0.8 2
18 8119003 000101- SOLENOID VALVE,24VDC 1
19 1962016 000101- CLAMP, 10-16mm 5
20 8119203 000101- TUBING ID=12MM L=135MM 1
21 8119204 000101- TUBING ID=10MM L=360MM 1
22 8116100 000101- WATER SUPPLY TUBE 1
