ICE RS26 / RS28 / RS32
PARTS LIST
MAIN FRAME GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8310102 MAIN FRAME, WELDED 1
2 8310133 RUBBER GROMMET 5
3
8310930A PERISTALTIC PUMP, KIT 1
8310931 TUBING, PUMP 1
4 1421409 FLAT WASHER, M4×
∮
9×0.8 2
5 1422411 LOCK WASHER M4 2
6 1221412 SCREW, PAN HEAD, M4×12 2
7
8310119 10" WHEEL, PU TIRE 2
1612605 BALL BEARING,6205-2RS 4
8 1436025 RETAINING RING, 25MM 2
9 8310150 WHEEL CAP 2
10 6210131 NYLON, CLAMP 5
11 1421510 FLAT WASHER, M5×
∮
10×1.0 5
12 1221512 SCREW, PAN HEAD, M5×12 5
13 8310120 BRACKET, STAND 2
14 1421824 FLAT WASHER, M8×
∮
24×2.0 3
15 1422821 LOCK WASHER M8 3
16 1021825 BOLT, HEX, M8×25 3
17 8210118 STATIC STRAP 1
18 8310708A HORN, 24VDC, KIT 1
19 1421307 PLAT WASHER, M3×
∮
7×0.5 4
20 1211316 SCREW, PAN HEAD, M3×16 2
