ICE RS26 / RS28 / RS32
PARTS LIST
RECOVERY TANK COVER GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1221512 SCREW, PAN HEAD, M5×12 5
2 1421510 FLAT WASHER, M5×
∮
10×1.0 9
3 8310138A CAUTION LIGHT, KIT 1
4 1123507 LOCK NUT, M5 2
5 8310241 PLATE, CATUION LIGHT 1
6 8310202 RECOVERY TANK COVER 1
7
8310260 AMETK VACUUM MOTOR, 3 STAGE, KIT 1
8132006 CARBON BRUSH FOR VACUUM MOTOR 2
8 8310207 VACUUM HOSE 1
9 1962050 CLAMP, 2 INCH 2
10 1123608 LOCK NUT, M6 8
11 1421612 FLAT WASHER, M6×
∮
12×1.6 4
12 8310204 ADAPTER, VACUUM HOSE 1
13 8310205 GASKET, ADAPTER 1
14 8310230 GASKET, DUST FILTER 1
15 1021620 BOLT, HEX HEAD, M6×20 4
16 8310232 BRACKET 1
17 1421618 FLAT WASHER, M6×
∮
18×1.6 12
18 1022600 BOLT, HEX HEAD, M6×100 1
19 8310228 SUPPORT, RECOVERY TANK COVER 1
20 8310231 SLEEVE,
∮
6.4×
∮
9.5×4 1
21 1021616 BOLT, HEX HEAD, M6×16 1
22 8310236 SPACER, NYLON 1
23 8310235 SLEEVE,
∮
6.4×
∮
9.5×8 1
24 8310229 SEALING STRIP 1
25 1021610 BOLT, HEX HEAD, M6×10 2
26 1422616 LOCK WASHER, M6 3
27 1021820 BOLT, HEX HEAD, M8×20 4
28 1421824 FLAT WASHER, M8×
∮
24×2.0 4
29 8310203 PLATE, VACCUM MOTOR MNTG 1
30 8310208 ISOLATER, M6 3
31 8310209 BRACKET, VACCUM MOTOR 1
32 8310234 INSULATION 1
33 1311316 SCREW, SELF-TAPPING, ST4.8×16 4
34 8310206 SEAL, FAN 1
