Ice RS26 User Manual

25
ICE RS26 / RS28 / RS32
PARTS LIST
CONTROL PANEL GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1221512 SCREW, PAN HEAD, M5×12 8
2 1421510 FLAT WASHER, M5×
∮
10×1.0 11
3 8311703 DECAL, CONTROL PANEL 1
4 8311702 PLATE, CONTROL PANEL 1
5 8310712 GASKET, CONTROL PANEL 1
6
8310773 PCB, CONTROL PANEL (AGM / EN) 1
8310775 PCB, CONTROL PANEL (WET FLOODED / EN) 1
7 1221306 SCREW, PAN HEAD, M3×6 5
8 8310701 CONROL HOUSING 1
9 1421824 FLAT WASHER, M8×
∮
24×2.0 4
10 1422821 LOCK WASHER, M8 4
11 1021825 BOLT, HEX HEAD, M8×25 4
12 1321110 SCREW, SELF-TAPPING, ST3.5×10 3
13 1421409 FLAT WASHER, M4×
∮
9×0.8 3
14 8133610 LED LIGHT, KIT 1
15 8133601 BASE, LED LIGHT 1
16 1221520 SCREW, PAN HEAD, M5×20 3
17 8133602 COVER, LED LIGHT 1
18 4010316 ICE LOGO 1
19 8310711 GASKET, SWITCH PANEL 1
20 8310702 PLATE, SWITCH PANEL 1
21
8310704 DECAL, SWITCH PANEL, RS32 1
8312704 DECAL, SWITCH PANEL, RS28 1
8310750 DECAL, SWITCH PANEL, RS26 1
22 2010121 ICE LOGO, SMALL 1
23 8310709 ROCKER SWITCH 2
24 8310707 EMERGENCY STOP SWITCH 1
25 8310706A KEY SWITCH, KIT 1
