ICE RS26 / RS28 / RS32
PARTS LIST
SEAT & DETERGENT SYSTEM GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1221412 SCREW, HEX HEAD, M4×12 4
2 8133502 CLAMP 4
3 8133501 CARGO NET 1
4 1123810 LOCK NUT, M8 5
5 8310413 SUPPORT, SEAT 1
6 8117007 NYLON SPACER 1
7 8310415 TORSION SPRING 1
8 8310414 SLEEVE,
∮
8.2×
∮
11×15 1
9 1421816 FLAT WASHER, M8×
∮
16×1.6 2
10 1021830 BOLT, HEX HEAD, M8×30 1
11 8310411 PLATE, SEAT MNTG 1
12 8310133 RUBBER GROMMET 1
13 1512820 SCREW, HEX SOCKET, M8×20 4
14 8310402K SEAT, KIT 1
15 1021616 SCREW, HEX HEAD, M6×16 4
16 1421618 FLAT WASHER, M6×
∮
18×1.6 4
17 8310418 CUP HOLDER 1
18 8310419 BRACKET, CUP HOLDER 1
19 1123608 LOCK NUT, M6 2
20 8310460 SPACER 1
21 8310463 ADAPTOR, KEY 1
22 8310464 INSERT, LOCK 1
23 8310461 BOTTLE, DETERGENT 1
24 8310462 CAP, BOTTLE 1
25 1021820 BOLT, HEX HEAD, M8×20 2
26 1422821 LOCK WASHER, M8 2
27 1421828 FLAT WASHER, M8×
∮
28×2.5 5
28 8310465 BOX, DETERGENT BOTTLE 1
29 8310421 BRACKET 1
