ICE RS26 / RS28 / RS32
PARTS LIST
SQUEEGEE GROUP / 水刮组件
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8310506 PIN,
∮
10×45 2
2 8310590A LINEAR, ACTUATOR, KIT 1
3 8310320 PIN, COTTER 2
4 1121008 HEX NUT, M10 2
5 8310503 BRACKET, SQUEEGEE 1
6 8310240 VACUUM HOSE 1
7 1123115 LOCK NUT, M12 1
8 8310550 CASTER, 2 INCH 2
9 8310501 COMPRESSION SPRING, 1
10 8310504 ARM, SQGE LIFTING 1
11 8310505 FLEX BUSHING, TPU 2
12 8210525 SHORT CLAMP ASSEMBLY 1
13 1221575 SCREW, PAN HEAD, M5×75 1
14 8118624 SHAFT
1
15 8118623 SPACER
1
16 1123507 LOCK NUT, M5 1
17
8311514 CLAMP ASSEMBLY, RS26 1
8310514 CLAMP ASSEMBLY, RS28 / RS32 1
18
8311531 REAR BLADE, LINATEX, RS26 1
8310531 REAR BLADE, LINATEX, RS28 / RS32 1
8311541 REAR BLADE, PU, RS26, OPTION 1
8310541 REAR BLADE, PU, RS28 / RS32, OPTION 1
19
8311561 SQUEEGEE HOSING, RS26 1
8310561 SQUEEGEE HOSING, RS28 / RS32 1
20
8311562 RETAINER, SQUEEGEE, RS26 1
8310562 RETAINER, SQUEEGEE, RS28 / RS32 1
21
8311560 SQUEEGEE ASSEMBLY, RS26 1
8310560 SQUEEGEE ASSEMBLY, RS28 / RS32 1
22
8311534 FRONT BLADE, LINATEX, RS26 1
8310534 FRONT BLADE, LINATEX, RS28 / RS32 1
8311544 FRONT BLADE, PU, RS26, OPTION 1
8310544 FRONT BLADE, PU, RS28/ RS32, OPTION 1
23 1021835 BOLT, HEX HEAD, M8×35 2
24 8210518 KNOB, M8 4
25 8115404 SLEEVE,
∮
8×
∮
12.7×12.7 2
26 8116009 PROTECTIVE WHEEL 2
27 1421824 FLAT WASHER, M8×
∮
24×2 4
28 1123810 LOCK NUT, M8 2
29 8210309 PIN, COTTER 2
30 8310311 PIN,
∮
16×150 1
31 8310508 PIN,
∮
12×100 1
32 8310509 EXTENSION SPRING 2
33 1031212 BOLT, HEX HEAD, M12×120 1
34 1421030 FLAT WASHER, M10×
∮
30×2.5 1
35 1021060 BOLT, HEX HEAD, M10×60 1
36 8310507 ADAPTER 1
