38 ICE RS26+ / RS32+
OPERATOR MANUAL
SQUEEGEE GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1021265 BOLT, HEX HEAD, M12
×
65 2
2 8310314 FLAT WASHER, M13×
∮
55×3 1
3 8320503 TORSION SPRING 1
4 8321516 PLASTIC WASHER
φ
16.2×
φ
30×1.5 4
5 8310320 PIN, COTTER 2
6 8310506 PIN,
∮
10×45 2
7 8320501 LINEAR, ACTUATOR 1
8 8310507 ADAPTER 1
9 8321513 EXTENSION SPRING 2
10 8701002 KNOB M8×70 1
11 8211506 SHAFT 1
12 8211504 SHOULDER BOLT 2
13 8321503 BRACKET, SQUEEGEE INSTALL 1
14 8310270 VACUUM HOSE 1
15 1123807 HEX NUT,M8 1
16 1421824 FLAT WASHER, M8×
∮
24×2.0 6
17 8321511 BRACKET, SQUEEGEE SWING 1
18 8211508 BUSHING 1
19 1123810 LOCK NUT M8 5
20 8210525 SHORT CLAMP ASSEMBLY 1
21 1221575 SCREW, PAN HEAD, M5×75 1
22 8118624 SHAFT 1
23 8118623 SPACER 1
24 1123507 LOCK NUT, M5 1
25
8311514 CLAMP ASSEMBLY, RS26+ 1
8310514 CLAMP ASSEMBLY, RS32+ 1
26
8311531 REAR BLADE, LINATEX, RS26+ 1
8310531 REAR BLADE, LINATEX, RS32+ 1
8311541 REAR BLADE, PU, RS26+, OPTION 1
8310541 REAR BLADE, PU, RS32+, OPTION 1
27 1021616 BOLT, HEX HEAD, M6×16 2
28 1421612 FLAT WASHER, M6×
∮
12×1.6 2
29 8116009 PROTECTIVE WHEEL 2
30 8115404 SLEEVE,
∮
8×
∮
12.7×12.7 2
