ICE RS26+ / RS32+ 39
OPERATOR MANUAL
SQUEEGEE GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
31 8210532 KNOB, M10 2
32 8118200 LEFT BRACKET 1
33 8310550 CASTER, 2 INCH 2
34
8311570 SQUEEGEE ASSEMBLY, RS26+ 1
8310580 SQUEEGEE ASSEMBLY, RS32+ 1
35
8311534 FRONT BLADE, LINATEX, RS26+ 1
8310534 FRONT BLADE, LINATEX, RS32+ 1
8311544 FRONT BLADE, PU, RS26+, OPTION 1
8310544 FRONT BLADE, PU, RS32+, OPTION 1
36
8311562 RETAINER, SQUEEGEE, RS26+ 1
8310562 RETAINER, SQUEEGEE, RS32+ 1
37 1021835 BOLT, HEX HEAD, M8×35 2
38
8311561 SQUEEGEE HOSING, RS26+ 1
8310561 SQUEEGEE HOSING, RS32+ 1
39 8210518 KNOB, M8 4
40 8118300 RIGHT BRACKET 1
41 1123115 LOCK NUT, M12 2
42 1421132 FLAT WASHER
φ
13×
φ
32×1.5 3
43 8321514 SLEEVE,
φ
12×
φ
16×8.5 2
44 8320507 BUSHING 2
45 8321512 BRACKET, SQUEEGEE 1
46 8310508 PIN,
∮
12×100 1
47 8210309 PIN, COTTER 2
48 8310311 PIN,
∮
16×150 1
To Next Page
