CONTROLLER GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1021616 SCREW, HEX HEAD, M6×16 12
2 1422616 LOCK WASHER, M6 18
3 1421618 FLAT WASHER, M6×
∮
18×1.6 15
4 8310480 FUSE, 150A 1
5 8114705 INSULATOR 3
6 8310422 BRACKET, INSULATOR 2
7 8310133 RUBBER GROMMET 2
8 8310740 CIRCUIT BREAKER, 5A 1
9 8014068 CIRCUIT BREAKER, 10A 1
10 8310450 BRACKET, SCRUB HEAD LIFTING 1
11 1211330 SCREW, PAN HEAD, M3×30 2
12 8310425 BRACKET 2
13 1021825 BOLT, HEX HEAD, M8×25 5
14 1422821 LOCK WASHER, M8 5
15 1421828 FLAT WASHER, M8×
∮
28×2.5 5
16 1123305 LOCK NUT, M3 4
17 1434300 WASHER, TOOTH, M3 4
18 8310423 MICRO SWITCH 1
19 1421307 FLAT WASHER, M3×
∮
7×0.5 2
20 1211320 SCREW, PAN HEAD, M3×20 2
21 8310763 OFF BOARD CHARGER SOCKET 1
22 8112030 POWER CORD, BATTERY CHARGER, US 1
23 1123507 LOCK NUT, M5 4
24 8210106A ON BOARD BATTERY CHARGER, 25A 1
25 1121505 HEX NUT, M5 4
26 8310452 BRACKET, BATTERY CHARGER 1
27 1421510 FLAT WASHER, M5×
∮
10×1.0 6
28 1221520 SCREW, HEX HEAD, M5×20 4
29 8310790 MAIN CONTROLLER 1
30 1423612 FLAT WASHER M6×
∮
12×1, COPPER 10
31 1023612 HEX BOLT M6 X 12, COPPER 10
32 1422513 LOCK WASHER,M5 2
33 1221525 SCREW, HEX HEAD, M5×25 2
