ICE RS26 / RS28 / RS32
PARTS LIST
SCRUB HEAD LIFTING GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8310320 PIN, COTTER 1
2 8210301 PIN,
∮
9.5×38 1
3 8310311 PIN,
∮
16×150 1
4 8310312 PIN,
∮
16×57 4
5 8210309 PIN, COTTER 6
6 8310303A LINEAR ACTUATOR, KIT 1
7 8310305 PLATE, ARM, SCRUB HEAD LIFTING 2
8 8310314 FLAT WASHER, LARGE 2
9 8310313 PIN,
∮
12×90 1
10 1032090 BOLT, HEX HEAD, M10×90 1
11 1421030 FLAT WASHER, M10×
∮
30×2.5 4
12 8310304 BRACKET, SCRUB HEAD LIFTING 1
13 1421020 FLAT WASHER, M10×
∮
20×2 2
14 8310307 BUSHING, FLANGE 2
15 1123012 LOCK NUT, M10 3
16 8310144 SLEEVE,
∮1
6×
∮
18.6×25.4 4
17 8310118 ARM, SCRUB HEAD LIFTING 2
18 1011025 BOLT, HEX HEAD, M10×25 4
19 8310306 SLEEVE,
∮
10.5×
∮
18.5×34 2
20 8310308 SPRING 1
