ICE RS26 / RS28-OB / RS32
6'8:92/9:
58(/:'2.+'*2/,:/4--85;6895(
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8340517 SHOULDER BOLT, M8 1
2 1123808 LOCK NUT, M8 8
3
8310303A LINEAR ACTUATOR, KIT 1
4 8340133 DAMPER,RUBBER 2
5
1032200 BOLT, HEX HEAD, M12×100 2
6
1421132 FLAT WASHER,
ׯ
13×
ׯ
32×1.5 7
7 8340134 DAMPER,RUBBER 4
8 8340136 SHOULDER, M10 1
9 1021825 BOLT, HEX HEAD, M8×25 4
10
8340131 BRACKET, GUIDE 1
11 1421824 FLAT WASHER, M8×
ׯ
24×2.0 2
12 8117007 NYLON WASHER ,
ׯͳʹǤͻ
×
ׯ
24×2.5 4
13 8125415
JOURNAL BEARING
4
14
8125414 SLEEVEE, STAINLESS STEEL 2
15 8133151 DAMPER, RUBBER 3
16 1435013
WAVE WASHER,
ׯ
13×
ׯ
24×0.5
2
17 8340120 BRACKET, ORBTIAL HEAD LIFT 1
18 1123115 NUT,LOCK, M12 2
19 8340132 DAMPER 6
20 8340137 BRACKET, ACTUATOR 1
21 1421030 FLAT WASHER, M10×
ׯ
30×2.5 3
22 1123012 LOCK NUT, M10 3
23
8340135 SHOULDER BOLT, M10 2
