Now that your game is assembled it is me to set the game opons. The game’s scoring is shown on the Tower Score

Chart and it is based on price per play. See the next page for available Tower Score Charts which can be replaced by

calling service. You cannot change the values used in the Tower Score Charts. You can change the bonus amount and

how much to charge per play.

To determine which Tower Score Chart the game is using, when the power is applied to the game, the balloon to the

right will display which Tower Score Chart being used. The display at the top shows the soware version. If you want to

change the cost of the game, then contact ICE Service Department to order a new Score Chart Tower.

Open the cabinet’s lower drawer and at the back you will nd the user control panel. Pressing the “PROG” buon will

enter the programming mode. The lower right balloon shows which opon you are adjusng while the upper display

shows the value for that opon. Pressing the “SELECT” buon will advance to the next opon. The “UP” and “DOWN”

buons will change the opon’s value.

Programming Opons for Whack N Win Revision 1.06

Opon Min Max Inc

0 Game Volume 0 7 1

This opon adjusts the general sounds and voices in the game.

1 Music Volume 0 7 1

This opon adjusts the music only.

2 Coin 1 line 0 10 1

How many “coin clicks” or pulses from coin 1 coin line to start a game. This line would be the switch with the white/brown wire

aached to it.

3 Coin Mulplier 0 10 1

How many pulses each coin is worth on coin line 2. This line would be the switch with the white/red wire aached to it. This opon

should be set to 1 unless you are using dierent coins that have dierent values. For example if the coin you are using in coin 1 is a

quarter and coin line 2 is accepng $1.00 coins, then this would be set to 4, not 1. If coin line 2 is accepng the same coin as coin

line 1, then this would be set to 1.

4 DBV line 0 10 1

How many pulses is each coin worth on coin line 2. This line would be the switch with the white/orange wire aached to it (or DBV).

This opon depends on how you have congured your DBV for what currency your wish to accept. For example, if your coin 1 line

accepts quarters and you have congured your DBV to pulse 4 mes per dollar, then you would set this to 1. If your DBV pulses only

once per dollar, then you would set this to 4.

5 Discount 0 10 1

This opon allows you to give addional games, based on the amount of money inserted for credits purchased. So if you wanted to

give 3 games per $1.00 and each game cost was .50¢, then this would be set to 2. You would also have to set opon 6 to 1. Now

when two games are purchased in a row without hing the “Hit Pad” then the player will receive three games instead of two.

6 Games Discounted 0 20 1

This opon works when a value is set in opon 5 other than 0. This opon determines how many games to give when using the dis-

count opon. See opon 5 for further explanaon.

7 Aract Time 0 90 1 Aract me

This opon sets the me between aract cycles.
