22
※ The maximum ice capacity is based on 10 ℃ ambient / water temperature but may
vary depending on the installation condition; high temperature in summer may severely
affect the capacity.
CATEGORY UNIT
BUILT-IN ICE MAKER
A25B15 / A25O15 / A25G15
Maximum
manufacturing capacitor
kg/day
(at 10 ℃)
29
Dimesion
W x D x H
(mm)
378 x 624 x 855 (exclude Handle, Leg, Hinge)
Quantity of Ice EA 24
Rated Power V/Hz 230 V / 50 Hz
Weight
Before Box kg 50
After Box kg 63.2
Cooling
UNIT
Refrigerant - R-134a
Capacity kcal/hr 1065 (at 7.2 ℃)
Cooling
method
- Air-cooled
Controlling the size of ice - Controlling the temperature with EVA SENSOR
Controlling the detection
of full ice
-
Controlling the temperature with electronic sensor
Differential application per ambient temperature
(automatic PCB control)
Refrigerant Controlled by - MICOM Control
Power Consumption W 500
Water Supply Condition ℃ 10 ~ 27
Water supply pressure psig 7~113
Ambient temperature ℃ 10 ~ 38
10. Specifications
