iCharger 458DUO - Buttons Function & Icons Description

458DUO
Dual Balance Charger/Discharger/DC Power
- 8 -
Buttons Function & Icons Description
Please refer to below chart for button functions
Symbols
Operation
Function
<>
Click the rotary switch
Initial interface: Enter CHANNEL SELECTION
Other interface: Confirm function or enter submenu
<>
Press the rotary switch
for 2 seconds
MEMORY SELECTION interface: Enter Management Menu
Other interface: Save and return to Previous Menu
<>
Turn the rotary switch
Turn anticlockwise: The menu scrolls up or the adjustment
value becomes smaller
Turn clockwise: The menu scrolls down or the adjustment
value becomes larger
When the round button is pressed and turned the rotary switch
one time at the same time, it will be triggered automatically and
continuously before releasing the pressed button.
<TAB/SYS>
Click TAB/SYS
Startup interface: Enter SELECT INPUT POWER SUPPLY
Other interface: a. can act as backspace when editing program
name on MEMORY SETUP. b. Control out of focus c. Not
save and return to Previous Menu
<TAB/SYS>
Press TAB/SYS for 2 seconds
Initial interface: Enter SYSTEM MENU
Other interface: Not save and return to Previous Menu
< STATUS-x>
Click STATUS-x
Program runtime: Switch the display information page of
CH-x channel
< STATUS-x>
Press STATUS-x for 2 seconds
Initial interface: Start internal resistance measurement
Program runtime: The parameter change interface pops up
< STOP/START-x>
Click STOP/START-x
Initial interface: Enter MEMORY SELECTION; click again to
return the initial interface
Program runtime: Stop running program
< STOP/START-x>
Press STOP/START-x for 2
seconds
Initial interface: Enter Run Program
Run Program Interface: Run the selected program
< STATUS-x> +
< STOP/START-x>
Press STATUS-x and
STOP/START-x at the same
time for 2 seconds
Initial Interface: Enter MONITOR SETTINGS
< STOP/START-12>
Press STOP/START-1 and
STOP/START-2 at the same
time for 2 seconds
Run Program interface: CH-1 and CH-2 run the same program
Please refer to below chart for the icons on the interface:
Icon
Function and Usage
Fan status: a. Grey shows not running
b. Green shows running (the higher the green shows, the faster the fan runs, and vice versa)
SD card status: a. Grey shows the SD card is not inserted
b. Green shows the SD card has been inserted and can be used normally
USB status: a. Grey for no USB connection
b. Green for USB connection
c. Data transfer to PC, red dot flashes
TYPE-C PD charge permit function
