Installing the Car Seat
1. Install the infant car seat rearward-facing on the vehicle seat and
ensure that it is close to the backrest of the vehicle seat (Figure 1)
2. Put the lap strap of vehicle belt across the slots in the infant car
seat and insert the latch of the vehicle belt into its buckle (Figure 2)
3. Put the shoulder strap of the vehicle seat belt across the slot in the
back of infant car seat, behind the headrest, and tighten it (Figure 3)
4. Ensure that the vehicle seatbelt is tightened and make sure that it is
not twisted or knotted. Adjust the handle to the forward placement
so that it contacts the backrest of the vehicle seat (Figure 4)
IMPORTANT: Once fitted, the vehicle seat belt and the handle of the
infant car seat cannot be located in the position shown in Figure 2. If
in doubt, consult the manufacturer.
1
3 4
2
CLICK
buckle
latch
Do not use any other connection points than those marked
WARNING！
