Ickle Bubba Mercury - Manual Location

1
14
15
16
20
17
19
22
23
18
21
Manual Location
12
11
10
9
9
8
7
6
5
4
3
3
2
1
13
(1)
(2)
1. Handle
2. Handle button
3. Shoulder pad
4. Crotch pad
5. Buckle
6. Webbing
7. Centre function
adjustment
8. Adjustment belt
9. Side webbing guide
10. Canopy
11. Headrest
12. Inner pad
13. Carrier shell
14. Connecting hook
15. ISOFIX connector
16. ISOFIX release button
17. ISOFIX tube button
18. Release button
19. Base cover
20. Indicator window of green/
orange switch for carrier
installed with base
21. Indicator window of
ISOFIX
locked
22. Adjustment button of
support leg
23. Indicator window of support
leg worked
2
