COMPONENTS
B
A
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
A Handlebar & Cover
B Handlebar Adjuster
C Right Folding Button
D Left Folding Button
E Seat Unit
F Seat Disassembly Button
G Brake Bar
H Storage Basket
I Rear Wheel
J Wheel Disassembly Button
K Canopy
L Bumper Bar
M Canopy Connector
N Recline Buttons
O Revolving Wheel Lock
P Front Wheel
Q Seat/Carry Cot Frame*
R Carry Cot Fabric
S Seat Unit Fabric
T Chassis
U Carry Cot Apron
V Raincover
W Tether Strap
S
U
W
V
T
*IMPORTANT: The Carry Cot/Seat Unit Frame (Q) and the Carry Cot Fabric (R) are already assembled. When
converting from carry cot mode to stroller mode, the carry cot fabric will need to be removed from the carry cot
frame in order for the seat unit to be assembled with component (S).
To Next Page
