Preparing the Carry cot
1. The carry cot fabric should already be attached to the carry cot/seat unit frame.
IMPORTANT: The position of the carry cot may need to be adjusted to make it level.
This can be done by firmly pressing on the recline buttons and making sure this all points
vertically downwards (a) located either side of the carry cot frame, as shown above.
Bumper Bar Installation
2. Line up the holes on each side before pushing firmly into place.
3. To remove, press the centre button (b) inwards whilst pulling the bumper bar upwards.
1
2 3
a
b
CARRYCOT SET UP
Canopy Installation
1 2
3
4
1. Take the longer strip from part (a) and thread it through the front section of the canopy fabric (b).
Repeat the same process with the shorter strip from part (a) by threading it through the rear part
of the canopy fabric.
2. Make sure the canopy connectors are facing inwards.
3. Insert the shorter strip from part (a) into the rear holes and the larger strip into the front holes of the
canopy connectors. Make sure to wrap elastic around the base of the connectors as per image.
4. With the canopy in place, fit the connectosr onto the frame.
