ICM Controls SC 5812 - Configuration Mode Settings

11
Conguration Mode Settings
2. 1
st
Stage Temperature Differential (1°F to 5°F) (0.5°C to 2.5°C)
Set the number of degrees between your “setpoint” temperature and your
“turn on” temperature.
Press the up or down button to set differential value.
Press the right button to advance to the next screen.
3. 2
nd
Stage Temperature Differential (1°F to 5°F) (0.5°C to 2.5°C)
Set the number of degrees between when stage 1 turns on and when
stage 2 turns on.
Press the up or down button to set differential value.
Press the right button to advance to the next screen.
4. 3
rd
Stage Temperature Differential (1°F to 5°F) (0.5°C to 2.5°C)
Set the number of degrees between when stage 2 turns on and when
stage 3 turns on.
Press the up or down button to set differential value.
Press the right button to advance to the next screen.
1. Temperature Scale (F or C)
Choose Fahrenheit or Celsius.
Press the up or down button to select.
Press the right button to advance to the next screen.
The setup screens for Configuration Mode are as follows:
