Icom DS-100 - Parts List; Logic Unit

S.=Surface mount
IC1 1140008940 S.IC MB90F583BPFV-G
IC2 1130009680 S.IC HN58X2432TI
IC3 1130007450 S.IC RTC-4553A
IC4 1110004710 S.IC S-80928ANMP-DDR-T2
IC5 1110004200 S.IC NJM2360M-TE3
IC6 1130008850 S.IC HD61202UFS
IC7 1130008850 S.IC HD61202UFS
IC8 1130008860 S.IC HD61203UFS
IC9 1110003870 S.IC NJM2058M-T1
IC10 1110003870 S.IC NJM2058M-T1
Q2 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q3 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q4 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R)
Q5 1590000420 S.TRANSISTOR RN1404 (TE85R)
Q6 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
D1 1720000360 S.DIODE HSU88TRF
D2 1750000020 S.DIODE 1SS184 (TE85R)
D3 1790001470 S.DIODE SB10-05PCP-TD
D4 1790001010 S.ZENER MA8043-L (TX)
X1 6050010290 S.XTAL CR-610 (7.9872 MHz)
X2 6050011030 S.XTAL DMX-26S 32.768KHZ
L1 6200009370 S.COIL SLF7032T-221MR29-2
L2 6200008880 S.COIL SLF7032T-681MR16-2
R1 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R2 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R3 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R4 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R5 7410000990 S.ARRAY EXB-V8V 470JV
R9 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R10 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R11 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R12 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R13 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R14 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R15 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R16 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R17 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R18 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R19 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R20 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R21 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R22 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R23 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R24 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R25 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R26 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R27 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R28 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R29 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R30 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R31 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R32 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R33 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R34 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R35 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R36 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R37 7030006600 S.RESISTOR RR0816P-822-D (8.2 kΩ)
R38 7030006460 S.RESISTOR RR0816P-152-D (1.5 kΩ)
R39 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R40 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R41 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R42 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R43 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R44 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R45 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R46 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R47 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R48 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R49 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R50 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R51 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R52 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R53 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R54 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R55 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R56 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R57 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R60 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R61 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R62 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R63 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R64 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R65 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R66 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R67 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R68 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R69 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R70 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R71 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R72 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R73 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R74 7510000900 S.THERMISTOR NTCCF2012 3SH 223KC-T
R75 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
R76 7030003790 S.RESISTOR ERJ3GEYJ 824 V (820 kΩ)
R77 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R78 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R79 7030003810 S.RESISTOR ERJ3GEYJ 125 V (1.2 MΩ)
R80 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R81 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R82 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R83 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R84 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R87 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R88 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R89 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R90 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R91 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R92 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R93 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R94 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R95 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R96 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R97 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R98 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R99 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R100 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R101 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R102 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R103 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R104 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R105 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R106 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R107 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C2 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C3 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C4 4030008890 S.CERAMIC C1608 JB 1C 273K-T-A
C6 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C7 4510006670 S.ELECTROLYTIC ECEV1CA471P
C8 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C9 4510005370 S.ELECTROLYTIC ECEV1AA221P
C10 4030011280 S.CERAMIC C1608 CH 1H 271J-T-A
C11 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C12 4510007120 S.ELECTROLYTIC ECEV1AA101SP
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C14 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C15 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C16 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C17 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C18 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
5 - 1
SECTION 5 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
