[MAIN UNIT][LOGIC UNIT]
S.=Surface mount
C19 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C20 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C21 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C24 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C25 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C28 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C29 4030009990 S.CERAMIC C1608 CH 1H 200J-T-A
C30 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C31 4550006660 S.TANTALUM ECST1CC226R
C32 4510005370 S.ELECTROLYTIC ECEV1AA221P
C33 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C34 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
J1 6510019500 S.CONNECTOR 52559-2290
J2 6510021300 S.CONNECTOR 52365-1091
J3 6510021860 CONNECTOR BH-800.8
DS1 5030001850 LCD TSD0402-UFFDCW
DS2 5040002310 S.LED SML-311YTT86
DS3 5040002310 S.LED SML-311YTT86
DS4 5040002310 S.LED SML-311YTT86
DS5 5040002310 S.LED SML-311YTT86
DS6 5040002310 S.LED SML-311YTT86
DS7 5040002310 S.LED SML-311YTT86
DS8 5040002310 S.LED SML-311YTT86
DS9 5040002310 S.LED SML-311YTT86
DS10 5040002310 S.LED SML-311YTT86
DS11 5040002310 S.LED SML-311YTT86
DS12 5040002310 S.LED SML-311YTT86
DS13 5040002310 S.LED SML-311YTT86
DS14 5040002310 S.LED SML-311YTT86
DS15 5040002310 S.LED SML-311YTT86
DS16 5040002310 S.LED SML-311YTT86
DS17 5040002310 S.LED SML-311YTT86
DS18 5040002310 S.LED SML-311YTT86
DS19 5040002310 S.LED SML-311YTT86
DS20 5040002310 S.LED SML-311YTT86
DS21 5040002310 S.LED SML-311YTT86
DS22 5040002310 S.LED SML-311YTT86
DS24 5040002310 S.LED SML-311YTT86
DS25 5040002310 S.LED SML-311YTT86
DS26 5040002310 S.LED SML-311YTT86
DS27 5040002310 S.LED SML-311YTT86
DS28 5040002310 S.LED SML-311YTT86
DS29 5040002310 S.LED SML-311YTT86
DS30 5040002310 S.LED SML-311YTT86
DS31 5040002310 S.LED SML-311YTT86
DS32 5040002310 S.LED SML-311YTT86
DS33 5040002310 S.LED SML-311YTT86
DS34 5040002310 S.LED SML-311YTT86
DS35 5040002310 S.LED SML-311YTT86
DS36 5040002310 S.LED SML-311YTT86
DS37 5040002310 S.LED SML-311YTT86
DS38 5040002310 S.LED SML-311YTT86
DS39 5040002310 S.LED SML-311YTT86
DS40 5040002310 S.LED SML-311YTT86
DS41 5040002310 S.LED SML-311YTT86
DS42 5040002310 S.LED SML-311YTT86
BT1 3020000020 LITHIUM CR2032
W1 8900006530 CABLE OPC-618
EP1 0910052953 PCB B 5475C
EP2 8930052541 LCD CONTACT SRCN-2349-SP-N-W-1
IC1 1110003200 S.IC TA31136FN (EL)
IC2 1130007610 S.IC µPD3140GS-E1 (DS8)
IC3 1110003750 S.IC M5218AFP 600C
IC4 1110003650 S.IC NJM2211M-TE1
IC5 1170000280 S.IC TLP121 (GB-TPL)
IC6 1130007420 S.IC TC7W14FU (TE12L)
IC8 1170000280 S.IC TLP121 (GB-TPL)
IC9 1110002030 IC TA7808S
IC10 1180001070 S.IC TA7805F (TE16L)
Q1 1580000700 S.FET 3SK292 (TE85R)
Q2 1580000490 S.FET 3SK166A-2-T7
Q3 1530002360 S.TRANSISTOR 2SC2714-Y (TE85R)
Q4 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q5 1560000330 S.FET 2SK210-GR (TE85R)
Q6 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q7 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q8 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q9 1590000660 S.TRANSISTOR DTC144TU T107
Q11 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q12 1590000660 S.TRANSISTOR DTC144TU T107
Q13 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q14 1590000660 S.TRANSISTOR DTC144TU T107
Q15 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q16 1590000660 S.TRANSISTOR DTC144TU T107
Q17 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q18 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q19 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q20 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q21 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q22 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
D2 1790001330 S.ZENER MA8036-L (TX)
D4 1790000640 S.VARICAP MA363B (TX)
D5 1790000640 S.VARICAP MA363B (TX)
D6 1750000550 S.DIODE 1SS355 TE-17
D8 1750000130 S.DIODE DA204U T107
D9 1750000550 S.DIODE 1SS355 TE-17
D10 1750000130 S.DIODE DA204U T107
D11 1750000130 S.DIODE DA204U T107
D12 1790000950 S.ZENER MA8056-M (TX)
D13 1790000950 S.ZENER MA8056-M (TX)
D14 1790000950 S.ZENER MA8056-M (TX)
FI1 2010002420 MONOLITH FL-310 (21R15AB)
FI2 2010002420 MONOLITH FL-310 (21R15AB)
FI3 2020001680 CERAMIC ALFY450E
X1 6070000210 S.DISCRIMINATOR CDBCA450CX24
X2 6050010800 S.XTAL CR-659 (21.25 MHz)
L1 6150003820 COIL LS-440
L2 6150003820 COIL LS-440
L3 6150003820 COIL LS-440
L4 6150003820 COIL LS-440
L5 6200003050 S.COIL NL 322522T-R82J-3
L6 6200004600 S.COIL MLF1608D R15K-T
L7 6200002410 S.COIL NL 252018T-056J
L8 6200003100 S.COIL NL 322522T-3R9J-3
L9 6130002360 S.COIL LB-257
L10 6200003090 S.COIL NL 322522T-2R7J-3
L11 6200004700 S.COIL MLR1608M R10K-T
L12 6200004700 S.COIL MLR1608M R10K-T
L13 6200004700 S.COIL MLR1608M R10K-T
L14 6200004920 S.COIL MLF1608A 2R2K-T
L15 6200002420 S.COIL NL 252018T-068J
R1 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R3 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R4 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R5 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R6 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R7 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R8 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R9 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R12 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
5 - 2
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
