J1 6510004880 Connector MR-DS-E 01 1
W1 8900009740 Cable OPC-945 1
W2 8900009690 Cable OPC-951 1
EP1 6910011940 Bead ZCAT2436-1330A-M 1
MP3 8410002340 2349 heatsink 1
MP4 8210017200 2349 front panel assembly 1
MP5 8210017150 2345 rear panel assembly 1
MP6 8930052060 2345 F-packing 1
MP7 8930052050 2345 R-packing 1
MP16 8930052430 2345 A-IC crip 1
MP18 8810008660 Screw PH BT M3 × 8 NI-ZU 5
MP19 8810008660 Screw PH BT M3 × 8 NI-ZU 7
MP20 8810004540 Screw M3 × 8 SUS 6
MP21 8810006050 Icom screw E7 6
MP22 8930052290 O ring (AD) 6
MP23 8850000690 Flat washer M3 (3×7×0.5) SUS 6
MP25 8810004540 Screw M3 × 8 SUS 2
MP26 8930034300 1542 ANT seal 1
MP27 8930049320 2288 VENT. sheet 1
REF. NO.
SECTION 6 MECHANICAL PARTS
[CHASSIS PARTS]
ORDER NO. DESCRIPTION QTY.
MP1 8610010560 2040 knob bolt (black) 2
MP2 8010018151 2345 mobile bracket-1 1
MP3 8850000500 Spring washer M5 SUS 2
MP4 8810001490 Screw PH A M5 × 20 SUS 2
MP5 8850000180 Flat washer M5 SUS 2
[UNPACKING]
REF. NO. ORDER NO. DESCRIPTION QTY.
6 - 1
REF. NO.
SP1 2520000110 Piezo buzzer PS1740P02 1
MP1 8510012590 2289 VCO case 1
[MAIN UNIT]
ORDER NO. DESCRIPTION QTY.
J3 6510021860 Connector BH-800.8 1
BT1 3020000110 Lithium CR2032 1
DS1 5030001850 LCD TSD0402-UFFDCW 1
EP2 8930052541 LCD contact SRCN-2349-SP-N-W-1 2
MP1 8210016790 2349 reflector 1
MP2 8930051950 2349 LCD holder 1
MP3 8930052530 2349 LCD filter 1
[LOGIC UNIT]
REF. NO. ORDER NO. DESCRIPTION QTY.
Screw abbreviations PH: Pan head BT: Self-Tapping
SUS: Stainless NI-ZU: Nickel-zinc
