1 - 1
SECTION 1 SPECIFICATIONS
‘‘
GENERAL
• Frequency coverage : 156.525 MHz (Ch 70) Rx only
• Mode : 16K0G2B
• Power supply requirement : 13.8 V DC (negative ground)
• Usable temperature range : –20˚C to +60˚C
• Current drain (at 13.8 V DC) : 1.0 A (approx.)
• Antenna impedance : 50 Ω (nominal)
• Output impedance (for testing) : 100 kΩ (nominal)
• Dimensions (projections not included) : 165(W)×110(H)×78(D) mm
• Weight : 1 kg (approx.)
‘‘
RECEIVER
• Receive system : Double conversion superheterodyne system
• Intermediate frequencies : 1st 21.7 MHz
2nd 450 kHz
• Sensitivity : -10 dBµ typical at 12 dB SINAD
• Adjacent channel selectivity : 70 dB
• Spurious response : 70 dB
• Intermodulation rejection ratio : 68 dB
• Hum and noise : –40 dB
Specifications are measured in accordance with EN301-025.
All stated specifications are subject to change without notice or obligation.
