SOFTWARE ADJUSTMENT-Continued
SQUELCH
LEVEL
(Wide)
[SqW]
(Narrow)
[SqN]
TEMP.
CORRECTION
<High power>
(VHF –10˚C)
[HP–]
(VHF +60˚C)
[HP–]
<Mid. power>
(VHF –10˚C)
[MP–]
(VHF +60˚C)
[MP–]
<Low power>
(VHF –10˚C)
[LP–]
(VHF +60˚C)
[LP–]
1
2
3
4
5
6
7
8
1
2
3
4
5
6
• Operating frequency : 146.1 MHz
• Connect an SSG to the antenna connector and set as
Level : 0.079 µV* (–129 dBm)
Modulation : 1 kHz
Deviation : ± 3.5 kHz
• Receiving
• Operating frequency : 445.1 MHz
• Receiving
• Operating frequency : 435.1 MHz
• Set an SSG as:
Level : 0.1 µV* (–127 dBm)
• Receiving
• Operating frequency : 810.1 MHz
• Set an SSG as:
Level : 0.25 µV* (–119 dBm)
• Receiving
• Operating frequency : 146.1 MHz
• Connect an SSG to the antenna connector and set as
Level : 0.071 µV* (–130 dBm)
Modulation : 1 kHz
Deviation : ± 3.5 kHz
• Receiving
• Operating frequency : 445.1 MHz
• Receiving
• Operating frequency : 435.1 MHz
• Set an SSG as:
Level : 0.1 µV* (–127 dBm)
• Receiving
• Operating frequency : 810.1 MHz
• Set an SSG as:
Level : 0.25 µV* (–119 dBm)
• Receiving
• Operating frequency : 146.0 MHz
• Receiving
• Operating frequency : 146.0 MHz
• Receiving
• Operating frequency : 146.0 MHz
• Receiving
• Operating frequency : 146.0 MHz
• Receiving
• Operating frequency : 146.0 MHz
• Receiving
• Operating frequency : 146.0 MHz
• Receiving
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
•Turn the [DIAL] to set to “F9” on the display.
• Push the [BAND] key.
•Turn the [DIAL] to set to “F9” on the display.
• Push the [BAND] key.
•Turn the [DIAL] to set to “F9” on the display.
• Push the [BAND] key.
•Turn the [DIAL] to set to “F9” on the display.
• Push the [BAND] key.
•Turn the [DIAL] to set to “F9” on the display.
• Push the [BAND] key.
•Turn the [DIAL] to set to “F9” on the display.
• Push the [BAND] key.
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
*This output level of a standard signal generator (SSG) is indicated as SSG’s open circuit.
