S.=Surface mount
6 - 7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
C4 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C5 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C9 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C10 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C11 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C12 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C14 4030008920 S.CERAMIC C1608 JB 1H 473K-T B
C15 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C16 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C17 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C18 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C19 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C21 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C24 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C25 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C29 4510004630
S.ELECTROLYTIC
ECEV1CA100SR B
C30 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C31 4510004630
S.ELECTROLYTIC
ECEV1CA100SR B
J1 6510023110 CONNECTOR 3008L-8P8C <KIN> B
DS1 5010000120 S.LED LN1371G-(TR) T
DS2 5010000120 S.LED LN1371G-(TR) T
DS3 5010000120 S.LED LN1371G-(TR) T
DS4 5010000120 S.LED LN1371G-(TR) T
DS5 5010000120 S.LED LN1371G-(TR) T
DS6 5010000120 S.LED LN1371G-(TR) T
DS7 5010000120 S.LED LN1371G-(TR) T
DS8 5010000120 S.LED LN1371G-(TR) T
DS10 5010000150 S.LED LT1EP53A T
DS11 5010000150 S.LED LT1EP53A T
MC1 7700002310 MICROPHONE EM-140 T
S1 2260000980 SWITCH SKHHLP014A B
EP1 6910012350 S.BEAD MMZ1608Y 102BT B
EP2 6910012350 S.BEAD MMZ1608Y 102BT B
EP3 6910012350 S.BEAD MMZ1608Y 102BT B
EP4 6910012350 S.BEAD MMZ1608Y 102BT B
EP5 0910055172 PCB B 5811B
IC1 1140011490 S.IC µPD789071MC-041-5A4-E1 B
IC3 1110006310 S.IC BD5245G-TR B
IC6 1130012030 S.IC BR24L02FV-WE2 B
Q1 1530001940 S.TRANSISTOR 2SC2712-BL (TE85R) B
Q2 1590000680 S.TRANSISTOR DTC114EUA T106 B
Q3 1590001330 S.TRANSISTOR DTA114EUA T106 B
Q4 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R) B
Q5 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R) B
Q6 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R) B
Q7 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R) B
Q8 1530001940 S.TRANSISTOR 2SC2712-BL (TE85R) B
Q9 1590001010 S.TRANSISTOR DTB113ZK T146 B
D1 1790000950 S.ZENER MA8056-M (TX) B
D3 1750000940 S.DIODE ISS400 TE61 B
D4 1750000940 S.DIODE ISS400 TE61 B
D5 1750000940 S.DIODE ISS400 TE61 B
D6 1750000940 S.DIODE ISS400 TE61 B
D7 1750000940 S.DIODE ISS400 TE61 B
D9 1750000940 S.DIODE ISS400 TE61 B
D10 1750000940 S.DIODE ISS400 TE61 B
D11 1750000940 S.DIODE ISS400 TE61 B
D12 1750000940 S.DIODE ISS400 TE61 B
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
[MAIN-A BOARD]
[MAIN-A UNIT]
D16 1730002280 S.ZENER MA8091-M (TX) B
D17 1730002280 S.ZENER MA8091-M (TX) B
D18 1730002280 S.ZENER MA8091-M (TX) B
X1 6060000610 S.CERAMIC EFOS4914E3 B
L1 6200001520 S.COIL MLF2012D R82K-T B
L2 6200001520 S.COIL MLF2012D R82K-T B
R2 7030000400 S.RESISTOR MCR10EZHJ 1.5 kΩ B
R3 7030000400 S.RESISTOR MCR10EZHJ 1.5 kΩ B
R4 7030000400 S.RESISTOR MCR10EZHJ 1.5 kΩ B
R5 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) B
R6 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) B
R7 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) B
R8 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) B
R9 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R10 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω) B
R11 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω) B
R12 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R13 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R14 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω) B
R15 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) B
R16 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R18 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R19 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R22 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R23 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R24 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R25 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R27 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R35 7030000400 S.RESISTOR MCR10EZHJ 1.5 kΩ B
R36 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R37 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R38 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R39 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R40 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R41 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R42 7030003860 S.RESISTOR ERJ3GE JPW V B
R43 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R44 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R45 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R46 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R47 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R48 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R49 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R50 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R51 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
C1 4030006850 S.CERAMIC C1608 JB 1H 471K-T B
C2 4510006220 S.ELECTROLYTIC ECEV1CA101UP B
C5 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C9 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C10 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C11 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C12 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C14 4030006900 S.CERAMIC C1608 JB 1H 103K-T B
C15 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C16 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C17 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C18 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C19 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C21 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C24 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C25 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C29 4510004630 S.ELECTROLYTIC ECEV1CA100SR B
C30 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C31 4510004630 S.ELECTROLYTIC ECEV1CA100SR B
J1 6510023110 CONNECTOR 3008L-8P8C <KIN> B
DS1 5010000120 S.LED LN1371G-(TR) T
DS2 5010000120 S.LED LN1371G-(TR) T
DS3 5010000120 S.LED LN1371G-(TR) T
DS4 5010000120 S.LED LN1371G-(TR) T
DS5 5010000120 S.LED LN1371G-(TR) T
DS6 5010000120 S.LED LN1371G-(TR) T
REF ORDER
DESCRIPTION M.
NO. NO.
