S.=Surface mount
6 - 9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
IC1 1180002390 S.REG S-812C33AMC-C2N-T2 T
IC2 1180002370 S.REG R1111N321B-TR T
IC50 1130011630 S.IC AD73311ARS T
IC101 1130008360 S.IC TC7SHU04FU (TE85L) B
IC103 1130006890 S.IC TC7S04FU (TE85R) T
IC151 1130010920 S.IC AMBE-2020 T
IC202 1130010460 S.IC TC7SH08FU (TE85L) B
IC203 1110005730 S.IC S-80928CNMC-G8Y-T2 B
IC204 1140010770 S.IC HD64F3687FP B
IC251 1110005290 S.IC NJM2115V-TE1 B
IC252 1110005430 S.IC CMX589AD5 B
IC253 1110006200 S.IC NJM13404V-TE1 B
IC254 1130004200 S.IC TC4S66F (TE85R) B
IC351 1120002980 S.IC MAX3226EAE-T T
Q50 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R) T
Q51 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q201 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q202 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q251 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q252 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q301 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q302 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q303 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q305 1590001660 S.TRANSISTOR XP4312 (TX) B
Q306 1590001660 S.TRANSISTOR XP4312 (TX) B
Q400 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R) B
Q401 1590000430 S.TRANSISTOR DTC144EUA T106 B
D151 1790001240 S.DIODE MA2S728-(TX) T
D152 1790001250 S.DIODE MA2S111-(TX) B
X101 6050011240 S.XTAL CR-708 (16.384 MHz) T
X201 6050011700 S.XTAL CR-760 (9.8304 MHz) T
L50 6200003960 S.COIL MLF1608A 1R0K-T T
L151 6200003960 S.COIL MLF1608A 1R0K-T B
L201 6200003960 S.COIL MLF1608A 1R0K-T B
L351 6200003960 S.COIL MLF1608A 1R0K-T T
R1 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R2 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220) T
R50 7030005010 S.RESISTOR ERJ2GEJ 681 X (680 Ω) T
R51 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R52 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R53 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R54 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R55 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R56 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R57 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R58 7030010040 S.RESISTOR ERJ2GE-JPW B
R59 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R60 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R100 7030010040 S.RESISTOR ERJ2GE-JPW T
R101 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) B
R102 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R103 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R151 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R152 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R201 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R202 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R203 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R204 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R205 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R206 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R209 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R211 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R212 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R216 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R217 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R218 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R219 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R221 7030010040 S.RESISTOR ERJ2GE-JPW B
R251 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R252 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R253 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R254 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R255 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R256 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R257 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R258 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
REF ORDER
DESCRIPTION M.
NO. NO.
6-4 UT-115 (OPTIONAL UNIT)
[MAIN UNIT]
R260 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R261 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R262 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R264 7310004610 S.TRIMMER EVM-2WSX80 B15 (104) T
R267 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R268 7030006610 S.RESISTOR ERJ2GEJ 394 X (390 kΩ) B
R269 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) B
R270 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R308 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) T
R309 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) T
R315 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) T
R316 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) T
R317 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R318 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) T
R400 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R401 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ) B
C1 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C2 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C5 4030017460 S.CERAMIC ECJ0EB1E102K B
C7 4550005980 S.TANTALUM TEESVA 1A 475M8L T
C8 4030016930 S.CERAMIC ECJ0EB1A104K T
C9 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C10 4030016930 S.CERAMIC ECJ0EB1A104K T
C11 4550006480 S.TANTALUM TEESVA 1C 475M8L T
C50 4030016930 S.CERAMIC ECJ0EB1A104K T
C51 4030016970 S.CERAMIC ECJ0EB1C223K T
C53 4030016930 S.CERAMIC ECJ0EB1A104K T
C54 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C55 4030016930 S.CERAMIC ECJ0EB1A104K T
C56 4030016950 S.CERAMIC ECJ0EB1A473K B
C57 4030016930 S.CERAMIC ECJ0EB1A104K T
C58 4030016930 S.CERAMIC ECJ0EB1A104K T
C102 4540000070 S.TRIMMER TZY2Z100A001 T
C103 4030017590 S.CERAMIC ECJ0EC1H070C T
C104 4030016930 S.CERAMIC ECJ0EB1A104K B
C106 4030016930 S.CERAMIC ECJ0EB1A104K T
C150 4550000460 S.TANTALUM TEESVA 1C 105M8L T
C151 4030016930 S.CERAMIC ECJ0EB1A104K T
C152 4030016930 S.CERAMIC ECJ0EB1A104K T
C153 4030016930 S.CERAMIC ECJ0EB1A104K T
C154 4030016930 S.CERAMIC ECJ0EB1A104K T
C155 4030016930 S.CERAMIC ECJ0EB1A104K T
C156 4030016930 S.CERAMIC ECJ0EB1A104K T
C157 4030016930 S.CERAMIC ECJ0EB1A104K T
C159 4030016930 S.CERAMIC ECJ0EB1A104K T
C201 4030016930 S.CERAMIC ECJ0EB1A104K B
C202 4030017590 S.CERAMIC ECJ0EC1H070C B
C203 4030016930 S.CERAMIC ECJ0EB1A104K B
C204 4030017390 S.CERAMIC ECJ0EC1H180J T
C205 4030016930 S.CERAMIC ECJ0EB1A104K B
C206 4030016790 S.CERAMIC ECJ0EB1C103K B
C207 4540000080 S.TRIMMER TZY2R200A001 T
C250 4030016930 S.CERAMIC ECJ0EB1A104K B
C252 4030017490 S.CERAMIC C1608 JB 1A 105K-T B
C253 4030017400 S.CERAMIC ECJ0EC1H220J B
C255 4030017490 S.CERAMIC C1608 JB 1A 105K-T B
C256 4030016930 S.CERAMIC ECJ0EB1A104K B
C257 4030017030 S.CERAMIC ECJ0EB1A273K B
C258 4030017030 S.CERAMIC ECJ0EB1A273K B
C259 4030017760 S.CERAMIC ECJ0EB1H222K T
C260 4030017490 S.CERAMIC C1608 JB 1A 105K-T B
C261 4030016930 S.CERAMIC ECJ0EB1A104K B
C262 4030017490 S.CERAMIC C1608 JB 1A 105K-T B
C263 4030016930 S.CERAMIC ECJ0EB1A104K B
C333 4030017460 S.CERAMIC ECJ0EB1E102K T
C351 4030011810 S.CERAMIC C1608 JB 1A 224K-T T
C352 4030011810 S.CERAMIC C1608 JB 1A 224K-T T
C353 4030011810 S.CERAMIC C1608 JB 1A 224K-T T
C354 4030011810 S.CERAMIC C1608 JB 1A 224K-T T
C355 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C401 4550006250 S.TANTALUM TEESVA 1A 106M8L B
J301 6510018440 S.CONNECTOR AXN430C330P B
EP1 0910057812 PCB B 6071B
REF ORDER
DESCRIPTION M.
NO. NO.
