Icom IC-2200H - Page 58

Feb. 2010
1
SECTION 6
.
PARTS LIST
[UNIT LIST]
Model Version
UNIT
LOGIC MAIN
MAIN-A
IC-2200H
[EUR] O O –
[TPE] O O –
[USA] O O –
[KOR] O O –
[SEA] O O –
IC-2200-T
[THA] O O –
IC-2200H
[EXP] O O –
[EUR-1] O O –
[AUS] O O –
[SEA-1] O O –
[EXP-1] O O –
[CHN] O O –
[CHN-01] O O –
[CHN-02] O O –
[TPE-1] O – O
[KOR-1] O
– O
[SEA-2] O
– O
IC-2200-T [THA-1] O – O
IC-2200H
[EXP-2] O – O
[AUS-1] O
– O
[SEA-3] O
– O
[EXP-3] O
– O
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]
IC1 1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [EUR] B 82.4/19.5
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [TPE]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [USA]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [KOR]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [SEA]
1140013480 S.IC M30220MA-142RP
(FX-2698B) [THA]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [EXP]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [EUR-1]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [AUS]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [SEA-1]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [EXP-1]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [CHN]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [CHN-01]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [CHN-02]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [TPE-1]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [KOR-1]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [SEA-2]
1140013480 S.IC M30220MA-142RP
(FX-2698B) [THA-1]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [EXP-2]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [AUS-1]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [SEA-3]
1140013550 S.IC M30220MA-143RP
(FX-2698A-2) [EXP-3]
IC2 1130004201 S.IC TC4S66F(TE85R,F) B 4.4/30.7
IC3 1110005340 S.IC NJM12902V-TE1-#ZZZB B 20.5/20.9
IC4 1110006210 S.IC BD5242FVE-TR B 98.7/15.5
IC5 1130014800 S.IC R1EX24064ATA00A B 64.7/24.4
IC6 1130011770 S.IC CD4066BPWR T 31.3/17.5
IC24 1110002861 S.IC TA75S393F(TE85R,F) T 19.8/13
IC514 1110005310 S.IC AN6123MS B 10.3/28.8
IC520 1130011770 S.IC CD4066BPWR T 18/22.6
IC521 1130008561 S.IC TC75S51F(TE85L,F) B 32/16.3
IC522 1130011770 S.IC CD4066BPWR B 41.1/15.8
IC524 1130011781 S.IC SN74AHC2G53HDCT3 B 37.1/11.2
IC525 1130011770 S.IC CD4066BPWR T 25.3/17.5
Q1 1530002691 S.TRA 2SC4116-GR(TE85R,F) T 21.2/16
Q2 1590000430 S.TRA DTC144EUA T106 B 65.8/18.9
Q3 1590001650 S.TRA XP4601(TX) B 71.9/6.1
Q5 1590000660 S.TRA DTC144TU T106 B 68.5/8.8
Q6 1510000510 S.TRA 2SA1576A T106R B 100.5/20.8
Q7 1530002691 S.TRA 2SC4116-GR(TE85R,F) B 105.3/17.2
Q8 1530002691 S.TRA 2SC4116-GR(TE85R,F) B 105.3/19.7
Q12 1530002691 S.TRA 2SC4116-GR(TE85R,F) B 105.4/24.8
Q513 1520000201 S.TRA 2SB798-T2-AZ DK B 47.2/27.9
Q514 1530002691 S.TRA 2SC4116-GR(TE85R,F) B 43/27.4
Q515 1510000510 S.TRA 2SA1576A T106R B 27.9/18
Q524 1510000510 S.TRA 2SA1576A T106R T 14.3/28.1
Q525 1590000430 S.TRA DTC144EUA T106 B 31.6/27.9
Q527 1590002230 S.TRA UMG2N TR B 24.8/13.8
Q528 1590002430 S.TRA DTA144EE TL T 20.8/18.3
D1 1730002281 S.ZEN MAZ8091GML T 17.8/8.5
D2 1790001251 S.DIO MA2S1110GL T 13.8/16.3
D3 1730002281 S.ZEN MAZ8091GML B 21.8/8.8
D4 1750000520 S.DIO DAN222TL B 14.7/17.1
D6 1750000370 S.DIO DA221 TL B 64.8/9.8
D7 1750000520 S.DIO DAN222TL T 85.3/3.9
D8 1750000520 S.DIO DAN222TL T 73.4/4.1
D9 1750000520 S.DIO DAN222TL T 61.4/4.7
D11 1710000611 DIO 1SS133 T77 (26M/M) [TPE]
1710000611 DIO 1SS133 T77 (26M/M) [KOR]
1710000611 DIO 1SS133 T77 (26M/M) [EUR-1]
1710000611 DIO 1SS133 T77 (26M/M) [TPE-1]
1710000611 DIO 1SS133 T77 (26M/M) [KOR-1]
D12 1750000940 S.DIO 1SS400 TE61 [THA] B 93.7/5
1750000940 S.DIO 1SS400 TE61 [THA-1]
