SECTION 6 PARTS LIST
6 - 1
IC1 1140006881 S.IC µPD753036GK-524-BE9
IC2 1110002820 S.IC NJM2100M-T1
IC3 1140004450 S.IC X24C01AS-3.0T6
IC5 1110004710 S.IC S-80928ANMP-DDR-T2
IC6 1180001150 S.IC S-81230SG-QB-T1
IC9 1110002810 S.IC NJM2070M-T1
Q1 1590000720 S.TRANSISTOR DTA144EUA T106
Q2 1590001860 S.TRANSISTOR UN9215 (TX)
Q3 1590000800 S.TRANSISTOR UN5119 (TX)
Q5 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R)
Q6 1560000840 S.FET 2SK1829 (TE85R)
Q7 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q10 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q11 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q12 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q14 1590001330 S.TRANSISTOR DTA114EUA T106
Q18 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R)
Q23 1590001390 S.FET 2SJ144-Y (TE85R)
Q25 1590002490 S.TRANSISTOR UMZ2N TR
Q27 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q28 1520000200 S.TRANSISTOR 2SB798-T2 DK
Q29 1590000680 S.TRANSISTOR DTC114EUA T106
Q101 1590002630 S.TRANSISTOR UMZ1N TR
[CSA], [CSA-1] only
D2 1750000550 S.DIODE 1SS355 TE-17
D4 1750000550 S.DIODE 1SS355 TE-17
D5 1750000550 S.DIODE 1SS355 TE-17 [CSA], [CSA-1]
1790001250 S.DIODE MA2S111-(TX) [ITA], [ITA-1]
D101 1750000550 S.DIODE 1SS355 TE-17 [CSA], [CSA-1]
1790001250 S.DIODE MA2S111-(TX) [ITA], [ITA-1]
D303 1790001250 S.DIODE MA2S111-(TX)
[ITA], [ITA-1] only
X1 6050010450 S.XTAL CR-627 (5.8368 MHz)
R2 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R4 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R5 7030003810 S.RESISTOR ERJ3GEYJ 125 V (1.2 MΩ)
R6 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R7 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R9 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R10 7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω)
R12 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R13 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R14 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R22 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R23 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R24 7030003820 S.RESISTOR ERJ3GEYJ 155 V (1.5 MΩ)
R25 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R26 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R27 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R30 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R31 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R32 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R33 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R34 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R35 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R36 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R37 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R38 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R39 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R40 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R41 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R42 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R43 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R45 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R46 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R49 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R50 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R51 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
REF ORDER
DESCRIPTION
NO. NO.
R52 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
R53 7030003820 S.RESISTOR ERJ3GEYJ 155 V (1.5 MΩ)
R54 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R55 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R56 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R57 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R58 7210001970 VARIABLE RV-244 (RK0971110) 10KA
R60 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R61 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R62 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R63 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R64 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R65 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R66 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R67 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R68 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R69 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R70 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R71 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R72 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R74 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R76 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R77 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R78 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R79 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R80 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R81 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R86 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R87 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R88 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R89 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R90 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R94 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R95 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R96 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R97 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R98 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R99 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R100 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R101 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R102 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R103 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R105 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R106 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R108 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R110 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R112 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
[CSA], [CSA-1]
7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
[ITA], [ITA-1]
R114 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
[ITA], [ITA-1]
7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
[CSA], [CSA-1]
R115 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
[CSA], [CSA-1]
R118 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R119 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
[CSA], [CSA-1] only
R200 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
[CSA], [CSA-1] only
R201 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
[CSA], [CSA-1] only
R202 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R301 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
[ITA], [ITA-1] only
R302 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
[ITA], [ITA-1] only
C1 4030009980 S.CERAMIC C1608 JB 1H 152K-T-A
C3 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C4 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C5 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C6 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C7 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
REF ORDER
DESCRIPTION
NO. NO.
S.=Surface mount
[MAIN UNIT]
[MAIN UNIT]
To Next Page
