Oct. 2008
15
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[LOGIC UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
S.=Surface mount
[VR-A UNIT]
[VR-B UNIT]
[MIC UNIT]
[PHONE UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R1 7210002910 VAR RV-310(RK0972210 10KB/10KB)
R2 7210002960 VAR RV-313(RK0972210 10KB/10KB)
J1 6510026670 S.CON IMSA-6281S-06Y900 T 21.6/5.1
J1 6510020711 S.CON 52793-1070(1090) T 9.2/2.4
S1 2250000640 ENC TP96D96E20-22F-10KB-3015
J1 6510000191 CON FM214-8SS(P)-1
J2 6510019971 S.CON 52808-1071 B 18.1/6.5
R1 7030006070 S.RES ERJ12YJ101U (100) T 24.6/5
R2 7030006070 S.RES ERJ12YJ101U (100) T 24.6/10.1
R3 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 23.1/12.6
C1 4030006880 S.CER C1608 JB 1H 472K-T B 27.7/9.6
C2 4030006880 S.CER C1608 JB 1H 472K-T T 23.1/2.5
C3 4030006880 S.CER C1608 JB 1H 472K-T T 23.1/13.9
J1 6510023891 CON S-G4617#01F 0
J2 6510019971 S.CON 52808-1071 B 26.6/4
EP1 6910014690 S.BEA MPZ1608S221A-T B 29.2/8.1
C25 4030011600 S.CER C1608 JB 1E 104K-T B 61.3/37.2
C26 4030017490 S.CER C1608 JB 1A 105K-T B 51.4/52.1
C27 4030011600 S.CER C1608 JB 1E 104K-T B 63.6/59.1
C28 4030017490 S.CER C1608 JB 1A 105K-T B 51.4/54.7
C44 4030006880 S.CER C1608 JB 1H 472K-T B 151.5/26.8
C45 4030006880 S.CER C1608 JB 1H 472K-T B 155.5/28.7
C47 4030006880 S.CER C1608 JB 1H 472K-T B 66.1/3.3
C49 4030006880 S.CER C1608 JB 1H 472K-T B 158.1/28.7
C50 4030006880 S.CER C1608 JB 1H 472K-T B 25.6/32.5
C70 4030006880 S.CER C1608 JB 1H 472K-T T 15.5/29.6
C71 4030006880 S.CER C1608 JB 1H 472K-T T 16.9/33.8
C72 4030006880 S.CER C1608 JB 1H 472K-T T 15.5/28.3
C73 4030006880 S.CER C1608 JB 1H 472K-T T 15.9/25.7
C74 4030017490 S.CER C1608 JB 1A 105K-T B 155.1/39
C101 4030011600 S.CER C1608 JB 1E 104K-T T 66.5/26.4
C102 4030006880 S.CER C1608 JB 1H 472K-T T 36.5/27.8
C103 4030012610 S.CER C2012 JB 1C 474K-T T 66.2/23.4
C104 4030011600 S.CER C1608 JB 1E 104K-T B 138/60.8
C105 4030011600 S.CER C1608 JB 1E 104K-T B 155.8/61.2
C106 4030019490 S.CER C2012 JB 1A 106K-T B 139.7/61.3
C107 4030011600 S.CER C1608 JB 1E 104K-T B 155.8/64.2
C108 4030019490 S.CER C2012 JB 1A 106K-T B 136.4/54.5
C109 4030019490 S.CER C2012 JB 1A 106K-T B 154.1/63.4
C110 4030011600 S.CER C1608 JB 1E 104K-T B 138/57.9
C158 4030017490 S.CER C1608 JB 1A 105K-T B 39.7/37.4
C170 4030006880 S.CER C1608 JB 1H 472K-T B 23.5/23.6
C171 4030006880 S.CER C1608 JB 1H 472K-T T 39.2/37.7
C172 4030018910 S.CER C1608 JB 0J 475K-T T 38.4/36.4
C211 4030006880 S.CER C1608 JB 1H 472K-T B 19.1/32.6
C212 4030011600 S.CER C1608 JB 1E 104K-T B 19.1/38.4
C1071 4030011600 S.CER C1608 JB 1E 104K-T T 127.8/14.5
C1072 4510009700 S.ELE EEEFK1C101P B 128.2/19.3
C1073 4510009820 S.ELE EEEFK1C470P B 129.1/5.1
C1074 4510009820 S.ELE EEEFK1C470P B 129.1/12.2
J1 6510018971 S.CON B4B-PH-SM4-TB(LF)(SN) B 140.7/29.4
J3 6510019971 S.CON 52808-1071 B 157.3/22.7
J4 6510019971 S.CON 52808-1071 B 61/7.7
J5 6510019971 S.CON 52808-1071 B 9.3/29.1
J101 6510024151 S.CON 50FY-BMT-TB(LF)(SN) B 39.2/25.8
J102 6510024151 S.CON 50FY-BMT-TB(LF)(SN) B 39.2/61
J301 6510019971 S.CON 52808-1071 B 77.2/59.4
DS1 5030003090 LCD S11325 <SUC>
DS2 5040002940 S.LED TLYU1002A(T02) T 172.5/14.3
DS70 5040002940 S.LED TLYU1002A(T02) T 61.5/49.1
DS71 5040002940 S.LED TLYU1002A(T02) T 53/49.1
DS73 5040002940 S.LED TLYU1002A(T02) T 53/59.2
DS74 5040002940 S.LED TLYU1002A(T02) T 61.5/59.2
DS76 5040002940 S.LED TLYU1002A(T02) T 70/59.2
DS77 5040002940 S.LED TLYU1002A(T02) T 70/49.1
DS79 5040002940 S.LED TLYU1002A(T02) T 78.5/59.2
DS80 5040002940 S.LED TLYU1002A(T02) T 78.5/49.1
DS82 5040002940 S.LED TLYU1002A(T02) T 87/59.2
DS83 5040002940 S.LED TLYU1002A(T02) T 87/49.1
DS85 5040002940 S.LED TLYU1002A(T02) T 95.5/59.2
DS86 5040002940 S.LED TLYU1002A(T02) T 95.5/49.1
DS88 5040002940 S.LED TLYU1002A(T02) T 104/59.2
DS89 5040002940 S.LED TLYU1002A(T02) T 104/49.1
EP2 8930076650 LCD SRCN-3015-SP-N-W (SHJ)
EP4 6910012350 S.BEA MMZ1608Y 102BT B 63.8/14.9
EP5 6910012350 S.BEA MMZ1608Y 102BT T 12.5/24.8
EP6 6910012350 S.BEA MMZ1608Y 102BT B 21.6/21.3
EP45 6910012350 S.BEA MMZ1608Y 102BT B 57.3/10.2
EP46 6910012350 S.BEA MMZ1608Y 102BT B 57.3/8.2
EP47 6910018930 S.BEA MPZ2012S601A T 41.9/23.2
EP48 6910018930 S.BEA MPZ2012S601A T 41.9/21.5
EP49 6910018930 S.BEA MPZ2012S601A B 41/21.1
EP50 6910018930 S.BEA MPZ2012S601A B 45.5/21
EP51 6910018930 S.BEA MPZ2012S601A B 65.4/7.4
EP52 6910018930 S.BEA MPZ2012S601A B 65.4/11.1
EP53 6910018930 S.BEA MPZ2012S601A B 8.8/25.3
EP54 6910018930 S.BEA MPZ2012S601A B 66.3/4.9
EP55 6910018930 S.BEA MPZ2012S601A B 43/21
