6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
L1 6200003261 S.COI NLV32T-101J
L3 6200003261 S.COI NLV32T-101J
L4 6200003261 S.COI NLV32T-101J
L6 6200003261 S.COI NLV32T-101J
C1 4030006880 S.CER C1608 JB 1H 472K-T
C2 4030006880 S.CER C1608 JB 1H 472K-T
C3 4030006880 S.CER C1608 JB 1H 472K-T
C4 4030006880 S.CER C1608 JB 1H 472K-T
C5 4030006880 S.CER C1608 JB 1H 472K-T
C6 4030006880 S.CER C1608 JB 1H 472K-T
C7 4030007130 S.CER C1608 CH 1H 101J-T
J1 6510000191 CON FM214-8SS(P)-1
J2 6510019971 S.CON 52808-1071
S.=Surface mount
[MODE UNIT]
REF ORDER
DESCRIPTION
NO. NO.
J1 6510019991 S.CON 52808-2271(2291)
