7 - 1
[FRONT UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
W19 8900009271 OPC-912A 1
W20 8900015160 OPC-916A 1
W21 8900009271 OPC-912A 1
W22 8900009271 OPC-912A 1
W24 8900009231 OPC-908A 1
W25 8900009660 OPC-964 1
W26 8900009231 OPC-908A 1
W27 8900009231 OPC-908A 1
EP1 0880000950 EX-2500 #01 1
EP2 6450001230 HLJ0999-01-480 (SNAP PLATE) 1
EP3 6450001230 HLJ0999-01-480 (SNAP PLATE) 1
MP1 8210018270 2072 FRONT PANEL (B)-1 1
MP2 8010017294 2072 SUB CHASSIS-4 1
MP3 8310052470 2072 WINDOW PLATE (A) 1
MP4 8930056340 2072 TEN KEY (A) 1
MP5 8930056260 2072 MODE KEY (A) 1
MP6 8930056270 2072 P-KEY (A) 1
MP7 8930045430 2072 T-A KEY 1
MP8 8930045440 2072 N-A KEY 1
MP9 8930045450 2072 S-L KEY 1
MP10 8930045460 2072 4-KEY 1
MP11 8610011120 KNOB N-273 (C) 2
MP12 8610010260 KNOB N-252 (incl. MP24) 2
MP13 8610010620 KNOB N-253 (A) (incl. MP24) 2
MP14 8610010633 KNOB N-268 BASE-3 (incl. MP15,MP16,MP18,MP20) 1
MP15 8930041391 1876 D-RUBBER-1 1
MP16 8610010040 KNOB N-239 FINGER REST 1
MP17 8930027470 1296 BRAKE PAD 1
MP18 8930037111 1691 BRAKE SHEET-1 1
MP19 8930041060 1876 BRAKE PLATE 1
MP20 8930032340 1424 N-SPRING 1
MP23 8610007420 KNOB SPRING NO.6601 3
MP24 8610007420 KNOB SPRING NO.6601 2
MP25 8820000771 1296 SCREW-1 1
MP26 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 5
MP27 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 2
MP28 8810009181 0TAP 1FLAT WASHER B0 2X5 NI-ZC3 (BT) 2
MP29 8810009181 0TAP 1FLAT WASHER B0 2X5 NI-ZC3 (BT) 5
MP30 8810009181 0TAP 1FLAT WASHER B0 2X5 NI-ZC3 (BT) 1
MP31 8810009181 0TAP 1FLAT WASHER B0 2X5 NI-ZC3 (BT) 2
MP32 8810009181 0TAP 1FLAT WASHER B0 2X5 NI-ZC3 (BT) 2
MP33 8810009181 0TAP 1FLAT WASHER B0 2X5 NI-ZC3 (BT) 2
MP34 8810009181 0TAP 1FLAT WASHER B0 2X5 NI-ZC3 (BT) 3
MP35 8810009391 SCREW BT B0 3X18NI-ZC3 (BT) 1
MP36 8930007840 THERMAL SHEET (K) 4
MP37 8930047080 SPONGE (FR) 1
MP38 8930047060 SPONGE (FS) 1
MP39 8930056531 THERMALLY SHEET (AA)-1 1
MP40 8610011130 KNOB N-273 (D) 1
MP41 8610010730 KNOB N-252 (A) 1
[S-LOGIC UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J301* 6510019991 52808-2271 1
J302* 6510019991 52808-2271 1
J303* 6510003401 B04B-EH-S (LF) (SN) 1
J501* 6510019971 52808-1071 1
J502* 6510019971 52808-1071 1
J507* 6510019971 52808-1071 1
J508* 6510019971 52808-1071 1
J601* 6510019991 52808-2271 1
J604* 6510003401 B04B-EH-S (LF) (SN) 1
S1* 2260001890 SKQDPA 1
S2* 2260001890 SKQDPA 1
S3* 2260001890 SKQDPA 1
S4* 2260001890 SKQDPA 1
S5* 2260001890 SKQDPA 1
S6* 2260001890 SKQDPA 1
S7* 2260001890 SKQDPA 1
S8* 2260001890 SKQDPA 1
S9* 2260001890 SKQDPA 1
S10* 2260001890 SKQDPA 1
S11* 2260001890 SKQDPA 1
S601* 2260001890 SKQDPA 1
MP1 8510001082 117 SHIELD CASE (A)-2 1
MP2 8510001101 SHIELD CASE (A) COVER (A)-1 1
MP3 8510005980 724 SHIELD CASE 1
MP4 8510005990 724 SHIELD CASE COVER 1
MP5 8930076790 THERMALLY SHEET (BO) 1
[PHONE BOARD]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1 6450001891 HLJ2305-0130909 1
J2 6450001791 HLJ7000-016010 (HONTAINOMI) 1
J3* 6510019971 52808-1071 1
[MIC BOARD]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1 6510000191 FM214-8SS (P)-1 1
J2* 6510019971 52808-1071 1
[PBT BOARD]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1* 6510019971 52808-1071 1
S1 2250000440 TP90N00E20-22.5-2494 1
S2 2250000410 TP90D96E20-30F-2178-1 1
SECTION 7
MECHANICAL PARTS
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[RIT BOARD]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1* 6510019971 52808-1071 1
S1 2250000340 EVQ-VCJF0324B 1
[DISPLAY BOARD]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J503* 6510019991 52808-2271 1
J505* 6510019991 52808-2271 1
J1001* 6510019991 52808-2271 1
J1002* 6510019991 52808-2271 1
DS1001 5030002150 DLC-83006S4GT 1
DS1002 5080000421 MBS 3 UA1W 70N ASSY 1
EP1 8930046361 SRCN-2072-SP-N-W-1 2
MP1 8930045491 2072 LCD HOLDER-1 1
MP2 8210015251 2072 REFLECTOR-1 1
MP3 8930046520 2072 LCD FILTER 1
MP4 8930046790 THERMAL SHEET (BT) 2
