Apr. 2009
1
SECTION 5
PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[LOGIC UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1130013750 S.IC EM639165TS-7G T 109/62.6
IC2 1130013750 S.IC EM639165TS-7G T 84.1/62.6
IC21 1130015113 S.IC JS28F128J3D-75(SX-3073A-3) T 103.2/37.1
IC51 1130011591 S.IC IDT70V24L15PFG B 119.8/87.1
IC53 1110005731 S.IC S-80928CNMC-G8Y-G B 65.8/89.4
IC54 1130007431 S.IC TC7S14FU(TE85R,F) B 61/88.6
IC55 1130012600 S.IC SN74AHC1G04DCKR B 58.1/87.9
IC102 1130013010 S.IC SN74AHC1G08DCK3 T 115.7/35.5
IC103 1140014730 S.IC HD6417751RBG240V T 70.8/30.7
IC105 1130015120 S.IC CY22393FXC(SX-3073F) B 97.8/18
IC201 1130013750 S.IC EM639165TS-7G T 8.9/79.8
IC202 1130013750 S.IC EM639165TS-7G B 14.8/80.1
IC203 1140011571 S.IC HD64404BTDV T 40.7/80.6
IC208 1130014030 S.IC BD6516F-E2 T 65.8/95.2
IC209 1190001920 S.IC AK5355-VT-E2 B 90.8/6.7
IC210 1190001920 S.IC AK5355-VT-E2 B 76.7/6.7
IC211 1190001910 S.IC AK4384-VT-E2 B 65.9/6.7
IC604 1140014710 S.IC HD64F2370VFQ34V B 140.3/66.4
IC605 1140015050 S.IC XC9572XL-10TQG100C
(SX-3073E) B 131.9/35.3
IC607 1130013010 S.IC SN74AHC1G08DCK3 T 142.8/87
IC608 1130013010 S.IC SN74AHC1G08DCK3 T 148.5/87
IC609 1130005252 S.IC TC74HC08AF(EL,F) T 119/77.2
IC610 1130014800 S.IC R1EX24064ATA00A T 148/64.6
IC661 1130012600 S.IC SN74AHC1G04DCKR T 147.8/77.7
IC721 1130010111 S.IC TC7WH04FU(TE12L,F) B 150.5/43.3
IC851 1180003100 S.REG BD9302FP-E2 T 179.5/87.9
IC871 1180003100 S.REG BD9302FP-E2 T 180.1/52.2
IC901 1110003870 S.IC NJM2058M-TE1-#ZZZB B 141.1/6.6
IC902 1110003870 S.IC NJM2058M-TE1-#ZZZB B 124.1/6.6
Q725 1510000771 S.TRA 2SA1586-GR(TE85L,F) B 155/39
Q727 1530003900 S.TRA KTC4075 BL-RTK/P B 155.1/41.5
Q731 1590003680 S.TRA KRC402 RTK/P B 147.9/36.7
Q1031 1560001221 S.FET ECH8301-TL-E T 190.2/30.4
D51 1750001320 S.DIO KDS4148U RTK/P [USA] T 52.5/27.1
1750001320 S.DIO KDS4148U RTK/P [EUR]
1750001320 S.DIO KDS4148U RTK/P [EUR-1]
1750001320 S.DIO KDS4148U RTK/P [ESP]
1750001320 S.DIO KDS4148U RTK/P [KOR]
1750001320 S.DIO KDS4148U RTK/P [TPE]
1750001320 S.DIO KDS4148U RTK/P [CHN]
1750001320 S.DIO KDS4148U RTK/P [ITR]
1750001320 S.DIO KDS4148U RTK/P [EXP]
D52 1750001320 S.DIO KDS4148U RTK/P [EUR-1] T 52.5/23.6
1750001320 S.DIO KDS4148U RTK/P [ESP]
1750001320 S.DIO KDS4148U RTK/P [KOR]
1750001320 S.DIO KDS4148U RTK/P [TPE]
1750001320 S.DIO KDS4148U RTK/P [CHN]
1750001320 S.DIO KDS4148U RTK/P [FRA]
1750001320 S.DIO KDS4148U RTK/P [EXP]
D53 1750001320 S.DIO KDS4148U RTK/P [USA] T 52.5/25.3
1750001320 S.DIO KDS4148U RTK/P [EUR]
1750001320 S.DIO KDS4148U RTK/P [EUR-1]
1750001320 S.DIO KDS4148U RTK/P [TPE]
1750001320 S.DIO KDS4148U RTK/P [CHN]
D54 1750001320 S.DIO KDS4148U RTK/P [USA] T 52.5/28.8
1750001320 S.DIO KDS4148U RTK/P [EUR]
1750001320 S.DIO KDS4148U RTK/P [EUR-1]
1750001320 S.DIO KDS4148U RTK/P [ESP]
1750001320 S.DIO KDS4148U RTK/P [KOR]
1750001320 S.DIO KDS4148U RTK/P [TPE]
1750001320 S.DIO KDS4148U RTK/P [ITR]
D55 1750001320 S.DIO KDS4148U RTK/P [EUR] T 52.5/20.1
1750001320 S.DIO KDS4148U RTK/P [EUR-1]
1750001320 S.DIO KDS4148U RTK/P [ESP]
1750001320 S.DIO KDS4148U RTK/P [CHN]
1750001320 S.DIO KDS4148U RTK/P [ITR]
1750001320 S.DIO KDS4148U RTK/P [EXP]
D56 1750001320 S.DIO KDS4148U RTK/P [EUR-1] T 52.5/21.8
1750001320 S.DIO KDS4148U RTK/P [ESP]
1750001320 S.DIO KDS4148U RTK/P [KOR]
1750001320 S.DIO KDS4148U RTK/P [TPE]
1750001320 S.DIO KDS4148U RTK/P [CHN]
1750001320 S.DIO KDS4148U RTK/P [FRA]
1750001320 S.DIO KDS4148U RTK/P [EXP]
D57 1750001320 S.DIO KDS4148U RTK/P [USA] T 52.5/18.3
1750001320 S.DIO KDS4148U RTK/P [EUR]
1750001320 S.DIO KDS4148U RTK/P [EUR-1]
1750001320 S.DIO KDS4148U RTK/P [TPE]
1750001320 S.DIO KDS4148U RTK/P [CHN]
D58 1750001320 S.DIO KDS4148U RTK/P [USA] T 52.5/16.6
1750001320 S.DIO KDS4148U RTK/P [EUR]
1750001320 S.DIO KDS4148U RTK/P [EUR-1]
1750001320 S.DIO KDS4148U RTK/P [ESP]
1750001320 S.DIO KDS4148U RTK/P [KOR]
1750001320 S.DIO KDS4148U RTK/P [ITR]
D59 1750001320 S.DIO KDS4148U RTK/P [EUR] T 52.5/14.8
1750001320 S.DIO KDS4148U RTK/P [EUR-1]
1750001320 S.DIO KDS4148U RTK/P [ESP]
1750001320 S.DIO KDS4148U RTK/P [CHN]
1750001320 S.DIO KDS4148U RTK/P [ITR]
1750001320 S.DIO KDS4148U RTK/P [EXP]
D60 1750001320 S.DIO KDS4148U RTK/P T 56.3/27.1
D61 1750001320 S.DIO KDS4148U RTK/P T 56.3/23.6
S.=Surface mount
[LOGIC UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
D62 1750001320 S.DIO KDS4148U RTK/P T 56.3/25.3
D63 1750001320 S.DIO KDS4148U RTK/P T 56.3/28.8
D66 1750001320 S.DIO KDS4148U RTK/P T 56.3/18.3
D67 1750001320 S.DIO KDS4148U RTK/P [EUR] T 56.3/16.6
1750001320 S.DIO KDS4148U RTK/P [EUR-1]
1750001320 S.DIO KDS4148U RTK/P [ITR]
1750001320 S.DIO KDS4148U RTK/P [FRA]
D68 1750001320 S.DIO KDS4148U RTK/P T 56.3/14.8
D101 1750001320 S.DIO KDS4148U RTK/P B 66.5/18.7
D102 1750001320 S.DIO KDS4148U RTK/P B 68.2/18.7
D206 1790000980 S.DIO MA742(TX) T 45.8/95.6
D207 1790000980 S.DIO MA742(TX) T 49.2/95.6
D711 1750001320 S.DIO KDS4148U RTK/P B 154.5/63.6
D715 1790001241 S.DIO MA2S7280GL B 154.5/65.2
D727 1750001320 S.DIO KDS4148U RTK/P B 155.1/43.7
D731 1750001180 S.DIO KDS122 RTK/P B 145/36.7
D732 1750001180 S.DIO KDS122 RTK/P B 150.8/36.6
D851 1750000960 S.DIO RB081L-20 T 188.1/88.1
D852 1750000960 S.DIO RB081L-20 T 171/86.2
D871 1750000960 S.DIO RB081L-20 T 171.4/52.2
D872 1750000960 S.DIO RB081L-20 T 188.7/52.2
D901 1790000980 S.DIO MA742(TX) B 161.5/33.9
D902 1790000980 S.DIO MA742(TX) B 176.5/33.9
D903 1790000980 S.DIO MA742(TX) B 164/33.9
D904 1790000980 S.DIO MA742(TX) B 166.5/33.9
D905 1790000980 S.DIO MA742(TX) B 169/33.9
D906 1790000980 S.DIO MA742(TX) B 171.5/33.9
D907 1790000980 S.DIO MA742(TX) B 174/33.9
D909 1790000980 S.DIO MA742(TX) T 120.5/11.1
D910 1790000980 S.DIO MA742(TX) T 120.5/13.6
D911 1790000980 S.DIO MA742(TX) T 101.3/6.3
D912 1790000980 S.DIO MA742(TX) T 101.3/3.8
D913 1790000980 S.DIO MA742(TX) B 159.6/31.1
X101 6050011610 S.XTA CR-751 SMD-49 25.000 MHz T 97.8/18.1
X201 6050010680 S.XTA CR-628 SMD-49 24.576 MHz T 36.8/63.7
X202 6050011910 S.XTA CR-780 DSX530G 48 MHz T 37.6/97.5
X601 6050011810 S.XTA CR-755 SMD-49 15.9744 MHz T 126.6/65.3
L801 6200005011 S.COI NLV25T-100J T 63/8
L803 6200005011 S.COI NLV25T-100J B 157.1/32.2
L851 6200013280 S.COI SLF10145T-330M1R6-PF T 196.3/89.3
L852 6200013280 S.COI SLF10145T-330M1R6-PF T 164.1/83.7
L853 6200010881 S.COI CDRH124NP-330MC T 192.9/77.3
L871 6200013280 S.COI SLF10145T-330M1R6-PF T 164.6/53.5
L872 6200013280 S.COI SLF10145T-330M1R6-PF T 196.9/49.9
L873 6200010881 S.COI CDRH124NP-330MC T 193.4/62
R1 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 107.7/24.3
R51 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 130.2/45.4
R52 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 63.2/89.4
R53 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 109.6/87.6
R54 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 129.3/88.4
R61 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 53.6/30.4
R62 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 56.6/30.4
R91 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 53.6/43.8
R92 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 56.6/37.6
R93 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 56/50.4
R94 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 55.2/47.4
R95 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 56.4/47.4
R96 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 57.6/47.4
R97 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 57.2/50.4
R98 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 59.6/50.4
R99 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 58.8/47.4
R102 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 71/19
R103 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 68.6/19
R104 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 54.8/50.4
R105 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 58.4/50.4
R106 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 71/19
R107 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 67.4/19
R108 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 69.8/19
R109 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 69.8/16
R110 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 71/16
R111 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 72.2/19
R112 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 68.6/16
R113 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 65/16
R114 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 66.2/16
R115 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 66.2/19
R116 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 65/19
R117 7030003260 S.RES ERJ3GEYJ 330 V (33) T 63.8/19
R118 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 63.8/16
R119 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 61.4/19
R120 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 56.6/24.4
R121 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 60.2/16
R122 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 61.4/16
R123 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 60.2/19
R125 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 67.4/16
R126 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 69.8/19
R128 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 72.2/16
R129 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 73.4/19
R130 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 73.4/19
R131 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 75.1/19
R132 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 72.2/19
R133 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 73.4/16
R134 7030003200 S.RES ERJ3GEYJ 100 V (10) T 77.6/19
